2 Instruction Descriptions
2-716
NJ-series Instructions Reference Manual (W502)
CIPUCMMSend
The CIPUCMMSend instruction sends a UCMM CIP message to a specified device on a CIP network.
* If you omit an input parameter, the default value is not applied. A building error will occur.
Instruction Name
FB/
FUN
Graphic expression ST expression
CIPUCMM
Send
Send Explicit
Message
UCMM
FB CIPUCMMSend_instance(Execute,
RoutePath, TimeOut, ServiceCode,
RqPath, ServiceDat, Size,
RespServiceDat, Done, Busy, Error,
ErrorID, ErrorIDEx, RespSize);
Variables
Name Meaning I/O Description Valid range Unit Default
RoutePath Route path
Input
Route path Depends on data type.
--- ---
TimeOut Timeout time Timeout time 1 to 65535 0.1 s 20
(2.0 s)
ServiceCode Service code Service code Depends on data type.
---
---
RqPath Request path Request path (class ID,
instance ID, attribute ID)
---
ServiceDat Command
data
Data to send
Depends on data type.
*
Size Number of
elements to
send
Number of elements to send 1
RespServiceD
at
Response
data
In-out Response data Depends on data type.
--- ---
RespSize Response
size
Output Response data size Depends on data type. Bytes ---
Boolean
Bit strings Integers
Real
numbers
Times, durations,
dates, and text strings
BOOL
BYTE
WORD
DWORD
LWORD
USINT
UINT
UDINT
ULINT
SINT
INT
DINT
LINT
REAL
LREAL
TIME
DATE
TOD
DT
STRING
RoutePath
OK
TimeOut OK
Service
Code
OK
ReqPath Refer to Function for details on the structure _sREQUEST_PATH.
ServiceDat
OK OK OK OK OK OK OK OK OK OK OK OK OK OK
An array, structure member, or union member can also be specified.
Size OK
CIPUCMMSend
CIPUCMMSend_instance
Execute Done
RoutePath Busy
TimeOut Error
ServiceCode ErrorID
RqPath ErrorIDEx
ServiceDat RespSize
Size
RespServiceDat
