2 Instruction Descriptions
2-744
NJ-series Instructions Reference Manual (W502)
EC_CopyMon
The EC_CopyMon instruction transfers packet data in an internal file in the main memory of the CPU
Unit to a SD Memory Card.
The EC_CopyMon instruction transfers packet data in an internal file in the main memory of the CPU
Unit to a SD Memory Card. FileName specifies the file name on the SD Memory Card.
Refer to the NJ-series CPU Unit Built-in EtherCAT Port User’s Manual (Cat. No. W505) for details on
EtherCAT communications.
Instruction Name
FB/
FUN
Graphic expression ST expression
EC_CopyMon Transfer Ether-
CAT Packets
FB EC_CopyMon_instance(Execute, File-
Name, Done, Busy, Error, ErrorID);
Variables
Name Meaning I/O Description Valid range Unit Default
FileName File name Input File name on the SD Memory
Card
Depends on data
type.
--- ---
Boolean
Bit strings Integers
Real
numbers
Times, durations,
dates, and text strings
BOOL
BYTE
WORD
DWORD
LWORD
USINT
UINT
UDINT
ULINT
SINT
INT
DINT
LINT
REAL
LREAL
TIME
DATE
TOD
DT
STRING
FileName OK
Function
Related System-defined Variables
Name Meaning Data type Description
_EC_PktSaving Saving Packet Data
File
BOOL This variable shows if the instruction is saving packet
data in an internal file in the main memory of the CPU
Unit.
TRUE: Saving.
FALSE: Not saving.
Additional Information
EC_CopyMon
Execute Done
FileName Busy
Error
ErrorID
EC_CopyMon_instance
