2 Instruction Descriptions
2-298
NJ-series Instructions Reference Manual (W502)
SEL
The SEL instruction selects one of two selections.
* If you omit the input parameter, the default value is not applied. A building error will occur.
Instruction Name FB/FUN Graphic expression ST expression
SEL Binary Selection FUN Out:=SEL(G, In0, In1);
Variables
Name Meaning I/O Description Valid range Unit Default
GGate
Input
FALSE: Selects In0.
TRUE: Selects In1.
Depends on data type. ---
FALSE
In0 and In1 Selections Selections *
Out Selection
result
Output Selection result Depends on data type.
--- ---
Boolean
Bit strings Integers
Real
numbers
Times, durations,
dates, and text strings
BOOL
BYTE
WORD
DWORD
LWORD
USINT
UINT
UDINT
ULINT
SINT
INT
DINT
LINT
REAL
LREAL
TIME
DATE
TOD
DT
STRING
GOK
In0 and In1 OKOKOKOKOKOKOKOKOKOKOKOKOKOKOKOKOKOKOKOK
Out OKOKOKOKOKOKOKOKOKOKOKOKOKOKOKOKOKOKOKOK
(@)SEL
EN ENO
G Out
In0
In1
To Next Page
