2 Instruction Descriptions
2-294
NJ-series Instructions Reference Manual (W502)
These instructions process Size elements from the beginning of arrays to process In1[] and In2[]. Pro-
cessing is performed for corresponding bits of corresponding elements. The processing results are
stored in corresponding elements of AryOut[]. In1[] to In2[] and AryOut[] must be the same data types.
The relationships between input and output variables are given in the following tables.
z AryAnd
If both bits are TRUE, then the processing result is TRUE. Otherwise, the processing result is FALSE.
z AryOr
If both bits are FALSE, then the processing result is FALSE. Otherwise, the processing result is TRUE.
Boolean
Bit strings Integers
Real
numbers
Times, durations,
dates, and text strings
BOOL
BYTE
WORD
DWORD
LWORD
USINT
UINT
UDINT
ULINT
SINT
INT
DINT
LINT
REAL
LREAL
TIME
DATE
TOD
DT
STRING
In1[] (array)OKOKOKOKOK
In2[] (array) Must be same data type as In1[]
Size OK
AryOut[]
(array)
Must be same data type as In1[]
Out OK
Function
Bit of ele-
ment in In1[]
Bit of ele-
ment in In2[]
Bit of Ary-
Out[]
FALSE FALSE FALSE
FALSE TRUE FALSE
TRUE FALSE FALSE
TRUE TRUE TRUE
Bit of ele-
ment in In1[]
Bit of ele-
ment in In2[]
Bit of Ary-
Out[]
FALSE FALSE FALSE
FALSE TRUE TRUE
TRUE FALSE TRUE
TRUE TRUE TRUE
