2-725
2 Instruction Descriptions
NJ-series Instructions Reference Manual (W502)
Communications Instructions
2
CIPUCMMSend
3 :
ReqPath.ClassID :=UINT#01;
ReqPath.InstanceID :=UINT#01;
ReqPath.isAttributeID:=TRUE;
ReqPath.AttributeID :=UINT#07;
CIPUCMMSend_instance(
Execute :=TRUE,
RoutePath :='02\192.168.250.2',
TimeOut :=UINT#20,
ServiceCode :=BYTE#16#0E,
RqPath :=ReqPath,
ServiceDat := Dummy,
Size :=UINT#0,
RespServiceDat:=ResDat);
IF (CIPUCMMSend_instance.Done=TRUE) THEN
Stage:=INT#0;
ELSIF (CIPUCMMSend_instance.Error=TRUE) THEN
Stage:=INT#30;
END_IF;
0:
DoUCMMTrigger:=FALSE;
Trigger :=FALSE;
ELSE
DoUCMMTrigger:=FALSE;
Trigger :=FALSE;
END_CASE;
END_IF;
// Processing after normal end
// Processing after error end
// Normal end
// Error end
// Send message
// Route path
// Timeout time
// Service code
// Request path
// Service data
// Number of elements
// Response data
