5.3 UL Standards
200 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
Drive Model
Maximum Applicable Motor
Output
kW (HP)
Input Voltage < 460 V
Maximum Applicable Motor
Output
kW (HP)
Input Voltage ≥ 460 V
Input Current Rating
A
Semiconductor Protection
Fuse Rated Current
Manufacturer: EATON/
Bussmann
4568 315 (400) 335 (450) 584 FWH-1200A
4675 355 (450) 370 (500) 657
FWH-1400A
FWH-1600A
*1
*1 A fuse with a large rated current for applications with repeated loads is recommended.
Table 5.10 Factory-Recommended Branch Circuit Protection: 400 V Class (HD)
Drive Model
Maximum Applicable Motor
Output
kW (HP)
Input Voltage < 460 V
Maximum Applicable Motor
Output
kW (HP)
Input Voltage ≥ 460 V
Input Current Rating
A
Semiconductor Protection
Fuse Rated Current
Manufacturer: EATON/
Bussmann
4002 0.55 (0.75) 0.55 (0.75) 1.9 FWH-50B
4004 1.1 (1.5) 0.75 (1) 3.5 FWH-50B
4005 1.5 (2) 1.5 (2) 4.7 FWH-50B
4007 2.2 (3) 2.2 (3) 6.7 FWH-60B
4009 3 (4) 3 (4) 8.9 FWH-60B
4012 4.0 (5) 3.7 (5) 11.7 FWH-60B
4018 5.5 (7.5) 5.5 (7.5) 15.8 FWH-80B
4023 7.5 (10) 7.5 (10) 21.2 FWH-90B
4031 11 (15) 11 (15) 30.6 FWH-150B
4038 15 (20) 15 (20) 41.3 FWH-200B
4044 18.5 (25) 18.5 (25) 50.5 FWH-200B
4060 22 (30) 22 (30) 43.1 FWH-225A
4075 30 (40) 30 (40) 58.3 FWH-250A
4089 37 (50) 37 (50) 71.5 FWH-275A
4103 45 (60) 45 (60) 86.5 FWH-275A
4140 55 (75) 55 (75) 105 FWH-300A
4168 75 (100) 75 (100) 142
FWH-325A
FWH-400A
*1
4208 90 (125) 90 (125) 170 FWH-500A
4250 110 (150) 110 (150) 207 FWH-600A
4296 132 (175) 150 (200) 248 FWH-700A
4371 160 (200) 185 (250) 300 FWH-800A
4389 200 (250) 220 (300) 373 FWH-1000A
4453 220 (300) 260 (350) 410 FWH-1200A
4568 250 (335) 300 (400) 465 FWH-1200A
4675 315 (400) 335 (450) 584
FWH-1400A
FWH-1600A
*1
*1 A fuse with a large rated current for applications with repeated loads is recommended.
◆ Low Voltage Wiring for Control Circuit Terminals
You must provide low voltage wiring as specified by the National Electric Code (NEC), the Canadian Electric
Code, Part I (CEC), and local codes. The NEC class 1 circuit conductor is recommended. Use the UL approved
class 2 power supply for external power supply.
Table 5.11 Control Circuit Terminal Power Supplies
Input/Output Terminals Power Supply Specifications
Digital input DI1 to DI8, D0V, DIC, D24V
Uses the LVLC power supply in the drive.
Use the UL Listed class 2 power supply for external power supply.
Analog input AI1 to AI3, A0V, +10V, -10V
Uses the LVLC power supply in the drive.
Use the UL Listed class 2 power supply for external power supply.
