10.5 Drive Watt Loss
364 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
10.5 Drive Watt Loss
◆ 400 V Class
Table 10.14 Drive Watt Loss (Heavy Duty: < 460 V)
Model
Rated Output Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
4002
1.8 8 38 15 53
4004
3.4 8 42 28 70
4005
4.8 8 46 37 83
4007
5.5 8 48 45 93
4009
7.2 8 37 61 98
4012
9.2 8 46 82 128
4018
14.8 8 65 140 205
4023
18 8 73 150 223
4031
24 8 101 211 312
4038
31 8 119 272 391
4044
39 8 148 354 502
4060
45 8 126 389 515
4075
60 8 165 527 692
4089
75 8 184 617 801
4103
91 8 237 779 1016
4140
112 5 300 956 1256
4168
150 5 486 1274 1760
4208
180 5 446 1432 1878
4250
216 5 558 1464 2022
4296
260 5 692 2061 2753
4371
304 5 824 2346 3170
4389
371 5 777 2212 2989
4453
414 2 963 2696 3659
4568
453 2 1086 3035 4121
4675
605 2 1328 3995 5323
Table 10.15 Drive Watt Loss (Heavy Duty: ≥ 460 V)
Model
Rated Output Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
4002 1.6
8 38 15 53
4004 2.1
8 39 19 58
4005 3.4
8 43 30 73
4007 4.8
8 46 43 89
4009 6.9
8 35 63 98
4012 7.6
8 39 71 110
4018 11
8 53 110 163
4023 14
8 59 120 179
4031 21
8 85 192 277
4038 27
8 99 245 344
4044 34
8 124 320 444
4060 40
8 115 361 476
4075 52
8 147 477 624
