11.20 Parameters Changed by PM Motor Code Selection
496 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
11.20 Parameters Changed by PM Motor Code Selection
Note:
The motor codes listed in these tables are the only correct setting values.
◆ Yaskawa SSR1 Series IPM Motors (Derated Torque)
Table 11.4 SSR1 Series Motor Code Setting for Specification of 400 V at 1750 min
-1
(r/min)
Parameter Unit Motor Code (setting value of E5-01)
E5-01 PM Mot Code Selection - 1232 1233 1235 1236 1238 123A 123B 123D
Voltage Class V 400 400 400 400 400 400 400 400
Capacity kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11
Motor Rotation Speed min
-1
1750 1750 1750 1750 1750 1750 1750 1750
E5-02 PM Mot Rated Power (kW) kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11.0
E5-03 PM Mot Rated Current
(FLA)
A 0.89 1.56 2.81 4.27 7.08 10.31 13.65 20.7
E5-04 PM Mot Pole Count - 6 6 6 6 6 6 6 6
E5-05 PM Mot Resistance (Ohms/
Phase)
Ω 25.370 9.136 6.010 3.297 1.798 0.982 0.786 0.349
E5-06 PM d-Axis Inductance (mH/
Phase)
mH 169.00 92.08 67.71 34.40 32.93 22.7 16.49 13.17
E5-07 PM q-Axis Inductance (mH/
Phase)
mH 197.50 119.56 81.71 54.00 37.70 26.80 23.46 15.60
E5-09 PM BackEMF Vpeak (mV/
(rad/ s))
mVs/rad 392.6 440.6 478.3 466.3 478.8 478.1 520.0 481.5
E5-24 PM BackEMF L-L Vrms
(mV/rpm)
mV/(r/
min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-09 Min Output Frequency Hz 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4
C5-17 Motor Inertia kgm
2
0.0011 0.0017 0.0023 0.0043 0.0083 0.014 0.017 0.027
L3-24 Acc@Rated Torque
*1
s 0.092 0.076 0.051 0.066 0.075 0.083 0.077 0.084
n5-02 Mot Inertia Acceleration
Time
s 0.092 0.076 0.051 0.066 0.075 0.083 0.077 0.084
n8-49 Heavy Load Id Current % -8.6 -11.5 -10.3 -19.8 -8.5 -11.0 -18.6 -12.5
*1 Default settings vary depending on the setting of o2-04 [Drive KVA Selection].
Table 11.5 SSR1 Series Motor Code Setting for Specification of 400 V at 1750 min
-1
(r/min)
Parameter Unit Motor Code (setting value of E5-01)
E5-01 PM Mot Code Selection - 123E 123F 1240 1242 1243 1244 1245 1246
Voltage Class V 400 400 400 400 400 400 400 400
Capacity kW 15 18 22 30 37 45 55 75
Motor Rotation Speed min
-1
1750 1750 1750 1750 1750 1750 1750 1750
E5-02 PM Mot Rated Power (kW) kW 15 18.50 22.00 30.00 37.00 45.00 55.00 75.00
E5-03 PM Mot Rated Current
(FLA)
A 27.5 33.4 39.8 52.0 65.8 77.5 92.7 126.6
E5-04 PM Mot Pole Count - 6 6 6 6 6 6 6 6
E5-05 PM Mot Resistance (Ohms/
Phase)
Ω 0.272 0.207 0.148 0.235 0.079 0.054 0.049 0.029
E5-06 PM d-Axis Inductance (mH/
Phase)
mH 10.30 8.72 6.81 5.4 4.08 3.36 3.16 2.12
E5-07 PM q-Axis Inductance (mH/
Phase)
mH 12.77 11.22 8.47 7.26 5.12 3.94 3.88 2.61
E5-09 PM BackEMF Vpeak (mV/
(rad/ s))
mVs/rad 498.8 509.5 503.9 561.7 528.5 558.1 623.8 594.5
