Omron Q2A Series Technical Manual

Specifications
10
10.6 Drive Exterior and Mounting Dimensions
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 367
10.6 Drive Exterior and Mounting Dimensions
◆ Open Chassis Type (IP20)
■ 4002 to 4023
Figure 10.1 Exterior and Mounting Dimensions Diagram 1
Table 10.18 400 V class (IP20)
Model
Dimensions mm (in.)
Weight
kg (lb.)
W H D D1 D2 W1 W2 H1 H2 t1 t2 d
4002
140
(5.51)
260
(10.24)
176
(6.93)
138
(5.43)
38
(1.50)
102
(4.02)
102
(4.02)
248
(9.76)
6
(0.236)
1.6
(0.063)
5
(0.197)
M5
3.5
(7.72)
4004
140
(5.51)
260
(10.24)
176
(6.93)
138
(5.43)
38
(1.50)
102
(4.02)
102
(4.02)
248
(9.76)
6
(0.236)
1.6
(0.063)
5
(0.197)
M5
3.5
(7.72)
4005
140
(5.51)
260
(10.24)
176
(6.93)
138
(5.43)
38
(1.50)
102
(4.02)
102
(4.02)
248
(9.76)
6
(0.236)
1.6
(0.063)
5
(0.197)
M5
3.5
(7.72)
4007
140
(5.51)
260
(10.24)
211
(8.31)
138
(5.43)
73
(2.87)
102
(4.02)
102
(4.02)
248
(9.76)
6
(0.236)
1.6
(0.063)
5
(0.197)
M5
3.9
(8.60)
4009
140
(5.51)
260
(10.24)
211
(8.31)
138
(5.43)
73
(2.87)
102
(4.02)
102
(4.02)
248
(9.76)
6
(0.236)
1.6
(0.063)
5
(0.197)
M5
3.9
(8.60)
4012
140
(5.51)
260
(10.24)
211
(8.31)
138
(5.43)
73
(2.87)
102
(4.02)
102
(4.02)
248
(9.76)
6
(0.236)
1.6
(0.063)
5
(0.197)
M5
3.9
(8.60)
4018
140
(5.51)
260
(10.24)
211
(8.31)
138
(5.43)
73
(2.87)
102
(4.02)
102
(4.02)
248
(9.76)
6
(0.236)
1.6
(0.063)
5
(0.197)
M5
4.2
(9.26)
4023
140
(5.51)
260
(10.24)
211
(8.31)
138
(5.43)
73
(2.87)
102
(4.02)
102
(4.02)
248
(9.76)
6
(0.236)
1.6
(0.063)
5
(0.197)
M5
4.2
(9.26)
