Parameter List
11
11.6 E: MOTOR
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 415
11.6 E: MOTOR
◆ E1: V/F PARAMETER MOTOR 1
No.
(Hex.)
Name Description
Default
(Range)
Ref.
E1-01
(0300)
Input AC Supply Voltage
Sets the drive input voltage.
NOTICE: Set this parameter to align with the drive input
voltage (not motor voltage). The protective features of the
drive will not function if this parameter is incorrect. Failure to
obey will cause incorrect drive operation.
400 V: 400 V
(400 V Class: 310 to 510
V)
610
E1-03
(0302)
V/f Pattern Selection
Sets the V/f pattern for the drive and motor. You can use one of the preset patterns or
you can make a custom pattern.
0 : CT_50-50Hzmax
1 : CT_60-60Hzmax
2 : CT_50-60Hzmax
3 : CT_60-72Hzmax
4 : VT_50-35HzmidV
5 : VT_50-50HzmidV
6 : VT_60-35HzmidV
7 : VT_60-50HzmidV
8 : HT_50Hz_125 V
9 : HTrq50Hz-165 V
A : HTrq60Hz-125V
B : HT_60Hz-165V
C : HF_60-90Hzmax
D : HF_60-120Hzmax
E : HF_60-180Hzmax
F : (F) : Custom
Note:
• When A1-02 = 2 [Control Method = OLVector], settings 0 through E are not
available.
• Set the correct V/f pattern for the application and operation area. An incorrect V/f
pattern can decrease motor torque and increase current from overexcitation.
F
(Determined by A1-02)
610
E1-04
(0303)
Max Output Frequency
Sets the maximum output frequency for the V/f pattern.
Determined by A1-02
and E5-01
(Determined by A1-02
and E5-01)
615
E1-05
(0304)
Max Output Voltage
Sets the maximum output voltage for the V/f pattern.
Determined by A1-02
(400 V Class: 0.0 - 510.0
V)
615
E1-06
(0305)
Base Frequency
Sets the base frequency for the V/f pattern.
Determined by A1-02
and E5-01
(0.0 - E1-04)
615
E1-07
(0306)
Mid A Frequency
Sets a middle output frequency for the V/f pattern.
Determined by A1-02
(0.0 - E1-04)
615
E1-08
(0307)
Mid A Voltage
Sets a middle output voltage for the V/f pattern.
Determined by A1-02，
C6-01 and o2-04
(400 V Class: 0.0 to
510.0 V)
616
E1-09
(0308)
Min Output Frequency
Sets the minimum output frequency for the V/f pattern.
Determined by A1-02
and E5-01
(Determined by A1-02,
E1-04, and E5-01)
616
E1-10
(0309)
Min Output Voltage
Sets the minimum output voltage for the V/f pattern.
Determined by A1-02 616
E1-11
(030A)
Expert
Mid B Frequency
Sets a middle output frequency for the V/f pattern.
0.0 Hz
(0.0 - E1-04)
616
E1-12
(030B)
Expert
Min Output Voltage
Sets minimum output voltage for the V/f pattern.
0.0 V 616
E1-13
(030C)
Expert
Base Voltage
Sets the base voltage for the V/f pattern.
0.0 V 616
