Parameter List
11
11.7 F: OPTIONS
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 421
◆ F2: ANALOG INPUT
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F2-01
(038F)
An.In Funct.Selection
Sets the input method for the analog reference used with AI-A3.
0 : 3 Independent Channels
1 : 3 Channels Added Together
0
(0, 1)
636
F2-02
(0368)
RUN
An.In Option Gain
Sets the analog reference gain as a percentage when the maximum output frequency is
100%.
Note:
Set F2-01 = 1 [An.In Funct.Selection = 3 Channels Added Together] to enable this
function.
100.0%
(-999.9 - +999.9%)
637
F2-03
(0369)
RUN
An.In Option Bias
Sets the analog reference bias as a percentage when the maximum output frequency is
100%.
Note:
Set F2-01 = 1 [An.In Funct.Selection = 3 Channels Added Together] to enable this
function.
0.0%
(-999.9 - +999.9%)
637
◆ F3: DIGITAL INPUT
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F3-01
(0390)
D.In Funct Selection
Sets the data format of digital input signals. Set o1-03 = 0 or 1 [FrqDisplay Unit
Selection = 0.01 Hz or 0.01% (100%=E1-04)] to enable this function.
Note:
The input signal type is BCD when o1-03 = 2 or 3 [rpmor User-selected units]. The
o1-03 value sets the setting units.
0 : BCD, 1% units
1 : BCD, 0.1% units
2 : BCD, 0.01% units
3 : BCD, 1 Hz units
4 : BCD, 0.1 Hz units
5 : BCD, 0.01 Hz units
6 : BCD (5-digit), 0.01 Hz
7 : Binary Input
8 : MF Digital Input
0
(0 - 8)
638
F3-03
(03B9)
D.In Data Length Select
Sets the number of bits to set the frequency reference with DI-A3.
0 : 8-bit
1 : 12-bit
2 : 16-bit
2
(0 - 2)
638
F3-10
(0BE3)
Expert
D0 Function Selection
Sets the function for terminal D0 of the DI-A3 when F3-01 = 8 [D.In Funct Selection =
MF Digital Input].
0
(0 - 4, 6 - 19F)
639
F3-11
(0BE4)
Expert
D1 Function Selection
Sets the function for terminal D1 of the DI-A3 when F3-01 = 8 [D.In Funct Selection =
MF Digital Input].
0
(0 - 4, 6 - 19F)
639
F3-12
(0BE5)
Expert
D2 Function Selection
Sets the function for terminal D2 of the DI-A3 when F3-01 = 8 [D.In Funct Selection =
MF Digital Input].
0
(0 - 4, 6 - 19F)
640
F3-13
(0BE6)
Expert
D3 Function Selection
Sets the function for terminal D3 of the DI-A3 when F3-01 = 8 [D.In Funct Selection =
MF Digital Input].
0
(0 - 4, 6 - 19F)
640
F3-14
(0BE7)
Expert
D4 Function Selection
Sets the function for terminal D4 of the DI-A3 when F3-01 = 8 [D.In Funct Selection =
MF Digital Input].
0
(0 - 4, 6 - 19F)
640
F3-15
(0BE8)
Expert
D5 Function Selection
Sets the function for terminal D5 of the DI-A3 when F3-01 = 8 [D.In Funct Selection =
MF Digital Input].
0
(0 - 4, 6 - 19F)
640
F3-16
(0BE9)
Expert
D6 Function Selection
Sets the function for terminal D6 of the DI-A3 when F3-01 = 8 [D.In Funct Selection =
MF Digital Input].
0
(0 - 4, 6 - 19F)
640
