12.10 o: KEYPAD
818 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
0 : YYYY/MM/DD
1 : DD/MM/YYYY
2 : MM/DD/YYYY
Note:
The Fault History in the Monitor Mode shows when faults occurred. Refer to Show Fault History on page 138 for more information.
■ o4-24 bAT Detection Selection
No.
(Hex.)
Name Description
Default
(Range)
o4-24
(310F)
RUN
bAT Detection Selection
Sets operation when the drive detects bAT [Keypad Battery Low Voltage] and TiM [Keypad Time
Not Set].
0
(0 - 2)
0 : Disabled
The drive will not detect bAT or TiM.
1 : Enable (Alarm Detected)
TiM or bAT shows on the keypad, and operation continues. The output terminal set for Alarm [H2-01 to H2-03 =
4] activates.
2 : Enable (Fault Detected)
The drive output shuts off and the motor coasts to stop. Fault relay output terminal 1NO-1CM activates, and 1NC-
1CM deactivates.
◆ o5: DATA LOGGER
The data log function saves drive status information as a CSV file in the micro SD memory card in the keypad.
Monitors Ux-xx are the source of data log information. You can record a maximum of 10 monitors.
Change the LCD keypad screen from the main menu to the Diagnostic Tools screen and select the data log
function. Set the number of the monitor to record and the sampling time, then start to record the data log.
Table 12.59 Setting Parameters for Data Log Items
No. Name Default Data Log Monitors
o5-03 Log Mon Data 1 101 U1-01 [Frequency Reference]
o5-04 Log Mon Data 2 102 U1-02 [Output Frequency]
o5-05 Log Mon Data 3 103 U1-03 [Output Current]
o5-06 Log Mon Data 4 107 U1-07 [DC Bus Voltage]
o5-07 Log Mon Data 5 108 U1-08 [Output Power]
o5-08 Log Mon Data 6 000 Not selected
o5-09 Log Mon Data 7 000 Not selected
o5-10 Log Mon Data 8 000 Not selected
o5-11 Log Mon Data 9 000 Not selected
o5-12 Log Mon Data 10 000 Not selected
NOTICE: Do not de-energize the drive or disconnect the keypad from the drive during log transfer communication. Failure to
obey can cause the log function to fail after you restore power or connect the keypad.
Note:
You can use a Micro SDHC card a maximum of 32 GB capacity.
■ Log File Specifications
Item Specification
File storage location A folder called [Log_File] is created in the root directory of the micro SD card.
Filename Q0xxx.csv
Note:
[xxx] identifies a 3-digit decimal number
Maximum number of files
999 (Q0001.csv through Q0999.csv)
Character code ASCII code
