Omron Q2A Series Technical Manual

11.18 E3-01 [M2 Control Method Selection] Dependent Parameters
488 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
11.18 E3-01 [M2 Control Method Selection] Dependent
Parameters
The values for the parameters in these tables depend on the values for parameter E3-01 [M2 Control Method
Selection]. Changing the setting for E3-01 [M2 Control Method Selection] will change the default settings.
Parameter Setting Range Unit
Motor 2 Control Method (setting value of E3-01)
V/f Control
(0)
PG V/f Control
(1)
OLVector
(2)
CLVector
(3)
C3-21 M2 Slip Comp Gain 0.0 to 2.50 0.1 0.0 - 1.0 1.0
C3-22 M2 Slip Comp DelayTime 0 to 10000 1 ms 2000 - 200 -
C5-22 M2 ASR PGain 1 0.00 to 300.00 0.01 - 0.20 - 20.00
C5-22 M2 ASR ITime 1 0.000 to 10.000 0.001 s - 0.200 - 0.500
C5-23 M2 ASR PGain 2 0.00 to 300.00 0.01 - 0.02 - 20.00
C5-24 M2 ASR ITime 2 0.000 to 10.000 0.001 s - 0.050 - 0.500
C5-26 M2 ASR Delay Time 0.000 to 0.500 0.001 s - - - 0.004
E3-04 M2 Max Out Frequency 40.0 to 590.0 0.1 Hz 60.0 60.0 60.0 60.0
E3-05 M2 Max Out Voltage
0.0 to 255.0
*1
0.1 V 200.0 200.0 200.0 200.0
E3-06 M2 Base Frequency 0.0 to 590.0 0.1 Hz 60.0 60.0 60.0 60.0
E3-07 M2 Mid A Frequency 0.0 to 590.0 0.1 Hz 3.0 3.0 3.0 0.0
E3-08 M2 Mid A Voltage
0.0 to 255.0
*1
0.1 V 15.0 15.0 11.0 0.0
E3-09 M2 Min Out Frequency 0.0 to 590.0 0.1 Hz 1.5 1.5 0.5 0.0
E3-10 M2 Min Out Voltage
0.0 to 255.0
*1
0.1 V 9.0 9.0 2.0 0.0
E3-11 M2 Mid B Frequency 0.0 to 590.0
Determined by
o1-04
0.0 0.0 0.0 0.0
E3-12 M2 Min Out Voltage
0.0 to 255.0
*1
0.1 V 0.0 0.0 0.0 0.0
E3-13 M2 Base Voltage
0.0 to 255.0
*1
0.1 V 0.0 0.0 0.0 0.0
*1 This is the value for 200 V class drives. Double the value for 400 V class drives.
