11.5 d: REFERENCE
412 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
d1-13
(028E)
RUN
Reference 13
Sets the frequency reference in the units from o1-03 [FrqDisplay Unit Selection].
Note:
The default setting is o1-03 = 1 [0.01% (100%=E1-04)] when A1-02 = 6, 7
[Control Method = PM AOLVector, PM CLVector].
0.00 Hz
(0.00 - 590.00 Hz)
593
d1-14
(028F)
RUN
Reference 14
Sets the frequency reference in the units from o1-03 [FrqDisplay Unit Selection].
Note:
The default setting is o1-03 = 1 [0.01% (100%=E1-04)] when A1-02 = 6, 7
[Control Method = PM AOLVector, PM CLVector].
0.00 Hz
(0.00 - 590.00 Hz)
593
d1-15
(0290)
RUN
Reference 15
Sets the frequency reference in the units from o1-03 [FrqDisplay Unit Selection].
Note:
The default setting is o1-03 = 1 [0.01% (100%=E1-04)] when A1-02 = 6, 7
[Control Method = PM AOLVector, PM CLVector].
0.00 Hz
(0.00 - 590.00 Hz)
593
d1-16
(0291)
RUN
Reference 16
Sets the frequency reference in the units from o1-03 [FrqDisplay Unit Selection].
Note:
The default setting is o1-03 = 1 [0.01% (100%=E1-04)] when A1-02 = 6, 7
[Control Method = PM AOLVector, PM CLVector].
0.00 Hz
(0.00 - 590.00 Hz)
593
d1-17
(0292)
RUN
Jog Reference
Sets the JOG frequency reference in the units from o1-03 [FrqDisplay Unit Selection].
Set H1-xx: MFDI Function Select = 6 [Jog Reference] to use the Jog frequency
reference.
Note:
o1-03 = 1 [0.01% (100%=E1-04)] when A1-02 = 6, 7 [Control Method = PM
AOLVector, PM CLVector].
6.00 Hz
(0.00 - 590.00 Hz)
593
◆ d2: REFERENCE LIMITS
No.
(Hex.)
Name Description
Default
(Range)
Ref.
d2-01
(0289)
FRef Upper Limit
Sets maximum limit for all frequency references. This value is a percentage of E1-04
[Max Output Frequency].
100.0%
(0.0 - 110.0%)
594
d2-02
(028A)
FRef Lower Limit
Sets minimum limit for all frequency references. This value is a percentage of E1-04
[Max Output Frequency].
0.0%
(0.0 - 110.0%)
594
d2-03
(0293)
Analog FRef Lower
Limit
Sets the lower limit of the master frequency reference (Multi-Step Speed 1) as a
percentage of E1-04 [Max Output Frequency].
0.0%
(0.0 - 110.0%)
594
◆ d3: JUMP FREQUENCY
No.
(Hex.)
Name Description
Default
(Range)
Ref.
d3-01
(0294)
Jump Frequency 1
Sets the median value of the frequency band that the drive will avoid.
0.0 Hz
(Determined by A1-02)
595
d3-02
(0295)
Jump Frequency 2
Sets the median value of the frequency band that the drive will avoid.
0.0 Hz
(Determined by A1-02)
595
d3-03
(0296)
Jump Frequency 3
Sets the median value of the frequency band that the drive will avoid.
0.0 Hz
(Determined by A1-02)
595
d3-04
(0297)
Jump Frequency Width
Sets the width of the frequency band that the drive will avoid.
1.0 Hz
(Determined by A1-02)
595
