11.11 o: KEYPAD
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 463
11.11 o: KEYPAD
◆ o1: KEYPAD DISPLAY
No.
(Hex.)
Name Description
Default
(Range)
Ref.
o1-02
(0501)
RUN
Mon.Sel@Power-Up
Sets the monitor item that the keypad screen shows after energizing the drive. Refer to
“U: Monitors” for information about the monitor items that the keypad screen can show.
This parameter is only available when using an LED keypad.
1 : FreqReference (U1-01)
2 : Direction
3 : OutFrequency (U1-02)
4 : OutCurrent (U1-03)
5 : User Monitor (o1-01)
1
(1 - 5)
805
o1-03
(0502)
FrqDisplay Unit
Selection
Sets the display units for the frequency reference and output frequency.
0 : 0.01 Hz
1 : 0.01% (100%=E1-04)
2 : rpm
3 : User-selected units
Determined by A1-02
(0 - 3)
805
o1-04
(0503)
V/f Pattern Unit for
Display
Sets the setting unit for parameters that set the V/f pattern frequency.
0 : Hz
1 : rpm
Determined by A1-02
(0, 1)
806
o1-05
(0504)
RUN
LCD Contrast
Adjustment
Sets the contrast of the LCD display on the keypad.
5
(0 - 10)
806
o1-10
(0520)
FrqDisplay Max Value
Sets the value that the drive shows as the maximum output frequency.
Determined by o1-03
(1 - 60000)
806
o1-11
(0521)
FrqDisplay Decimal
Places
Sets the number of decimal places for frequency reference and monitor values.
0 : (XXXXX) No Decimal Places
1 : (XXXX.X) 1 Decimal Place
2 : (XXX.XX) 2 Decimal Places
3 : (XX.XXX) 3 Decimal Places
Determined by o1-03
(0 - 3)
807
o1-24 to o1-35
(11AD - 11B8)
RUN
Cust.Monitor 1 to 12
Sets a maximum of 12 monitors as user monitors. This parameter is only available with
an LED keypad.
o1-24: 101
o1-25: 102
o1-26: 103
o1-27 to o1-35: 0
(0, 101 - 999)
807
o1-36
(11B9)
RUN
LCD Backlight
Brightness
Sets the intensity of the LCD keypad backlight.
3
(1 - 5)
807
o1-37
(11BA)
RUN
LCD Blight ON/OFF
Selection
Sets the automatic shut off function for the LCD backlight.
0 : OFF
1 : ON
1
(0, 1)
807
o1-38
(11BB)
RUN
LCD Blight Off-Delay
Sets the time until the LCD backlight automatically turns off.
60 s
(10 - 300 s)
808
o1-40
(11BD)
RUN
Home Screen Selection
Mode
Sets the monitor display mode for the Home screen. This parameter is only available
when using an LCD keypad.
0 : Custom Monitors
8 : Bar Graph
9 : Analog Gauge
10 : Trend Plot
0
(0, 8 - 10)
808
o1-41
(11C1)
RUN
1stMon Area Selection
Sets the horizontal axis used to show the monitor that was set in o1-24 [Cust.Monitor 1]
as a bar graph. This parameter is only available with an LCD keypad.
0 : +/- Area (- o1-42 - o1-42 )
1 : + Area (0 - o1-42 )
0
(0 - 1)
808
o1-42
(11C2)
RUN
1stMon Area Setting
Sets the horizontal axis value used to display the monitor that was set in o1-24 [Cust.
Monitor 1] as a bar graph. This parameter is only available with an LCD keypad.
100.0%
(0.0 - 100.0%)
808
To Next Page
