Parameter Details
12
12.2 b: APPLICATION
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 555
■ b5-92 EZsleep Level
No.
(Hex.)
Name Description
Default
(Range)
b5-92
(0B92)
RUN
EZsleep Level
Sets the value that the output frequency or motor speed must be less than for longer than b5-93
[EZsleep Time] to enter Sleep Mode.
0.0 Hz or 0 rpm (r/min)
(0.0 to 590.0 Hz or 0 to
35400 rpm (r/min))
Note:
When b5-90 [EZsleep Unit] changes, this parameter does not automatically update. Set this parameter again after you change b5-90.
■ b5-93 EZsleep Time
No.
(Hex.)
Name Description
Default
(Range)
b5-93
(0B93)
RUN
EZsleep Time
Sets the length of time that the output frequency or motor speed must be less than b5-92 [EZsleep
Level] to enter Sleep Mode.
5.0 s
(0.0 - 1000.0 s)
■ b5-94 EZsleep Wake Level
No.
(Hex.)
Name Description
Default
(Range)
b5-94
(0B94)
RUN
EZsleep Wake Level
Sets the level at which the drive resumes operation when exiting Sleep Mode.
0.00%
(0.00 - 600.00%)
Note:
The values of b5-20 [PID Unit Selection], b5-38 [PID SP User Scale for Display], and b5-39 [PID SP User digits for Display] set the
units. When b5-20, b5-38, and b5-39 change, this parameter does not automatically update. Set this parameter again after you change
b5-20, b5-38, and b5-39 are changed.
• When b5-95 = 1 [EZsleep Wake Mode = Absolute]:
When b5-09 = 0 [PID Output Level Selection = Normal output], and the PID Feedback [H3-xx = F] is less than
the value of b5-94 for a time longer than the value of b5-96 [EZsleep Wake Time], the drive will exit sleep and
start operation again. When b5-09 = 1 [Reverse output], and the PID feedback is more than setting value of b5-
94 for a time longer than the setting value of b5-96, the drive will exit sleep and start operation again.
• When b5-95 = 0 [Setpoint Delta]:
When b5-09 = 0, and the PID feedback is less than the value of “PID setpoint value - b5-94” for a time longer
than the value of b5-96, the drive will exit sleep and start operation again. When b5-09 = 1, and the PID
feedback is more than the value of “PID setpoint value + b5-94” for a time longer than the setting value of b5-
96, the drive will exit sleep and start operation again.
■ b5-95 EZsleep Wake Mode
No.
(Hex.)
Name Description
Default
(Range)
b5-95
(0B95)
EZsleep Wake Mode
Sets the wake-up mode to use when exiting Sleep Mode.
1
(0, 1)
0 : Setpoint Delta
1 : Absolute
■ b5-96 EZsleep Wake Time
No.
(Hex.)
Name Description
Default
(Range)
b5-96
(0B96)
EZsleep Wake Time
Sets the EZ Wake-up time.
1.0 s
(0.0 - 1000.0 s)
When the PID feedback is less than the value of b5-94 [EZsleep Wake Level] continuously for the time set in b5-
96, the drive will exit sleep and start operation again.
◆ b6: DWELL FUNCTION
The Dwell function momentarily holds the output frequency at start and stop.
