11.15 U: MONITORS
482 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
No.
(Hex.)
Name Description MFAO Signal Level Ref.
U6-80 to U6-83
(07B0 to 07B3)
OPT IP ADR1 to 4 Shows the currently available local IP Address.
• U6-80: 1st octet
• U6-81: 2nd octet
• U6-82: 3rd octet
• U6-83: 4th octet
No signal output
available
-
U6-84 to U6-87
(07B4 to 07B7)
Online Subnet 1 to 4 Shows the currently available subnet mask.
• U6-84: 1st octet
• U6-85: 2nd octet
• U6-86: 3rd octet
• U6-87: 4th octet
No signal output
available
-
U6-88 to U6-91
(07B8, 07B9,
07F0, 07F1)
Online Gateway 1 to 4 Shows the currently available gateway address.
• U6-88: 1st octet
• U6-89: 2nd octet
• U6-90: 3rd octet
• U6-91: 4th octet
No signal output
available
-
U6-92
(07F2)
Online Speed Shows the currently available communications speed.
10: 10 Mbps
100: 100 Mbps
No signal output
available
-
U6-93
(07F3)
Online Duplex Shows the currently available Duplex setting. No signal output
available
-
U6-98
(07F8)
First Fault Shows the contents of the most recent communication options fault (DeviceNet,
Modbus TCP/IP, EtherNet/IP).
No signal output
available
-
U6-99
(07F9)
Current Fault Shows the contents of current fault from communication options (DeviceNet, Modbus
TCP/IP, EtherNet/IP).
No signal output
available
-
◆ U8: Q2PACK MONITORS
No.
(Hex.)
Name Description MFAO Signal Level Ref.
U8-01 to U8-10
(1950 - 1959)
Q2pack Mon 1 to 10 Shows Q2pack Monitors 1 to 10.
Unit: 0.01%
10 V = 100% -
U8-11 to U8-13
(195A - 195C)
Q2pack Ver 1 to 3 Shows Q2pack Versions 1 to 3. No signal output
available
-
U8-18
(1961)
Q2pack Base Platform Shows the Q2pack platform version. No signal output
available
-
U8-21 to U8-25
(1964 - 1968)
Q2pack Mon 21 to 25 Shows Q2pack User Monitors 21 to 25.
0.01%
10 V = 100% -
U8-31 to U8-40
(196E - 1977)
Q2pack Mon 31 to 40 Shows Q2pack User Monitors 31 to 40.
0.01%
10 V = 100% -
U8-51 to U8-55
(1982 - 1986)
Q2pack Mon 51 to 55 Shows Q2pack User Monitors 51 to 55.
0.01%
10 V = 100% -
