11.8 H: TERMINALS
430 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
11.8 H: TERMINALS
◆ H1: DIGITAL INPUTS
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H1-01
(0438)
DI1 Function Selection
Sets the function for MFDI terminal DI1.
Note:
The default setting is 0 when the drive is initialized for 3-Wire Initialization [A1-03
= 3330].
1
(1 - 4, 6 - 19F)
666
H1-02
(0439)
DI2 Function Selection
Sets the function for MFDI terminal DI2.
Note:
The default setting is 0 when the drive is initialized for 3-Wire Initialization [A1-03
= 3330].
2
(1 - 4, 6 - 19F)
667
H1-03
(0400)
DI3 Function Selection
Sets the function for MFDI terminal DI3.
24
(0 - 19F)
667
H1-04
(0401)
DI4 Function Selection
Sets the function for MFDI terminal DI4.
7B
(0 - 19F)
667
H1-05
(0402)
DI5 Function Selection
Sets the function for MFDI terminal DI5.
Note:
The default setting is 0 when the drive is initialized for 3-Wire Initialization [A1-03
= 3330].
A
(0 - 19F)
667
H1-06
(0403)
DI6 Function Selection
Sets the function for MFDI terminal DI6.
Note:
The default setting is A when the drive is initialized for 3-Wire Initialization [A1-03
= 3330].
B
(0 - 19F)
667
H1-07
(0404)
DI7 Function Selection
Sets the function for MFDI terminal DI7.
Note:
The default setting is B when the drive is initialized for 3-Wire Initialization [A1-03
= 3330].
6
(0 - 19F)
667
H1-08
(0405)
DI8 Function Selection
Sets the function for MFDI terminal DI8.
Note:
The default setting is 6 when the drive is initialized for 3-Wire Initialization [A1-03
= 3330].
1B
(0 - 19F)
667
H1-21
(0B70)
DI1 Funct.Sel 2
Sets the second function for MFDI terminal DI1.
0
(1 - 4, 6 - 19F)
668
H1-22
(0B71)
DI2 Funct.Sel 2
Sets the second function for MFDI terminal DI2.
0
(1 - 4, 6 - 19F)
668
H1-23
(0B72)
DI3 Funct.Sel 2
Sets the second function for MFDI terminal DI3.
0
(1 - 4, 6 - 19F)
668
H1-24
(0B73)
DI4 Funct.Sel 2
Sets the second function for MFDI terminal DI4.
0
(1 - 4, 6 - 19F)
668
H1-25
(0B74)
DI5 Funct.Sel 2
Sets the second function for MFDI terminal DI5.
0
(1 - 4, 6 - 19F)
668
H1-26
(0B75)
DI6 Funct.Sel 2
Sets the second function for MFDI terminal DI6.
0
(1 - 4, 6 - 19F)
668
H1-27
(0B76)
DI7 Funct.Sel 2
Sets the second function for MFDI terminal DI7.
0
(1 - 4, 6 - 19F)
669
H1-28
(0B77)
DI8 Funct.Sel 2
Sets the second function for MFDI terminal DI8.
0
(1 - 4, 6 - 19F)
669
H1-40
(0B54)
Mbus 15C0h b0 Input
Function
Sets the MFDI function for bit 0 of Modbus register 15C0 (Hex.).
0
(1 - 4, 6 - 19F)
669
H1-41
(0B55)
Mbus 15C0h b1 Input
Function
Sets the MFDI function for bit 1 of Modbus register 15C0 (Hex.).
0
(1 - 4, 6 - 19F)
669
H1-42
(0B56)
Mbus 15C0h b2 Input
Function
Sets the MFDI function for bit 2 of Modbus register 15C0 (Hex.).
0
(1 - 4, 6 - 19F)
669
