7.7 Auto-Tuning Errors
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 289
7.7 Auto-Tuning Errors
This table gives information about errors detected during Auto-Tuning. If the drive detects an Auto-Tuning error,
the keypad will show the error and the motor will coast to stop. The drive will not send notification signals for
faults and alarms when Auto-Tuning errors occur.
Two types of Auto-Tuning errors are: Endx and Erx. Endx identifies that Auto-Tuning has successfully completed
with calculation errors. Find and repair the cause of the error and do Auto-Tuning again, or set the motor
parameters manually. You can use the drive in the application if you cannot find the cause of the Endx error.
Erx identifies that Auto-Tuning was not successful. Find and repair the cause of the error and do Auto-Tuning
again.
Code Name Causes Possible Solutions
End1 Excessive Rated Voltage Setting
The torque reference was more than 20% during
Auto-Tuning or the no-load current that was
measured after Auto-Tuning is more than 80%.
• Make sure that the input motor nameplate data is correct.
• Do Auto-Tuning again and correctly set the motor nameplate
data.
• If you can uncouple the motor and load, remove the motor
from the machine and do Rotational Auto-Tuning again.
• If you cannot uncouple the motor and load, use the results
from Auto-Tuning.
Code Name Causes Possible Solutions
End2 Iron Core Saturation Coefficient
The motor nameplate data entered during Auto-
Tuning is incorrect.
• Make sure that the input motor nameplate data is correct.
• Do Auto-Tuning again and correctly set the motor nameplate
data.
Auto-Tuning results were not in the applicable
parameter setting range, and E2-07 or E2-08 [Mot
Sat Coeff 2] have temporary values.
• Examine and repair damaged motor wiring.
• If you can uncouple the motor and load, remove the motor
from the machine and do Rotational Auto-Tuning again.
Code Name Causes Possible Solutions
End3 Rated Current Setting Alarm
The rated current value is incorrect. Do Auto-Tuning again and set the correct rated current shown on
the motor nameplate.
Code Name Causes Possible Solutions
End4 Adjusted Slip Calculation Error
The Auto-Tuning results were not in the applicable
parameter setting range.
The motor rated slip that was measured after
Stationary Auto-Tuning was 0.2 Hz or lower.
The motor rated slip that was measured after
compensation with E2-08 [Mot Sat Coeff 2] is not
in the applicable range.
The secondary resistor measurement results were
not in the applicable range.
• Make sure the input motor nameplate data is correct.
• Do Rotational Auto-Tuning again and correctly set the motor
nameplate data.
• If you cannot uncouple the motor and load, do Stationary
Auto-Tuning 2.
Code Name Causes Possible Solutions
End5 Resistance Tuning Error
The Auto-Tuning results of the Line-to-Line
Resistance were not in the applicable range.
• Make sure that the input motor nameplate data is correct.
• Examine and repair damaged motor wiring.
Code Name Causes Possible Solutions
End6 Leakage Inductance Alarm
The Auto-Tuning results were not in the applicable
parameter setting range.
Make sure that the input motor nameplate data is correct, and do
Auto-Tuning again.
A1-02 [Control Method] setting is not applicable. • Examine the value set in A1-02.
• Make sure that the input motor nameplate data is correct, and
do Auto-Tuning again.
Code Name Causes Possible Solutions
End7 No-Load Current Alarm
The Auto-Tuning results of the motor no-load
current value were not in the applicable range.
Examine and repair damaged motor wiring.
Auto-Tuning results were less than 5% of the motor
rated current.
Make sure that the input motor nameplate data is correct, and do
Auto-Tuning again.
Code Name Causes Possible Solutions
Er-01 Motor Data Error
The motor nameplate data entered during Auto-
Tuning is incorrect.
• Make sure that the input motor nameplate data is correct.
• Do Auto-Tuning again and correctly set the motor nameplate
data.
The combination of the motor rated power and
motor rated current do not match.
• Examine the combination of drive capacity and motor output.
• Do Auto-Tuning again, and correctly set the motor rated power
and motor rated current.
