Omron Q2A Series Technical Manual

7.3 List of Fault, Minor Fault, Alarm, and Error Codes
252 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
Display (Hex.) ALM LED Type Ref.
End3 Flashing Auto-Tuning Errors 289
End4 Flashing Auto-Tuning Errors 289
End5 Flashing Auto-Tuning Errors 289
End6 Flashing Auto-Tuning Errors 289
End7 Flashing Auto-Tuning Errors 289
EP24v (0081) Flashing Alarm 277
Er-01 Flashing Auto-Tuning Errors 289
Er-02 Flashing Auto-Tuning Errors 290
Er-03 Flashing Auto-Tuning Errors 290
Er-04 Flashing Auto-Tuning Errors 290
Er-05 Flashing Auto-Tuning Errors 290
Er-08 Flashing Auto-Tuning Errors 290
Er-09 Flashing Auto-Tuning Errors 291
Er-10 Flashing Auto-Tuning Errors 291
Er-11 Flashing Auto-Tuning Errors 291
Er-12 Flashing Auto-Tuning Errors 291
Er-13 Flashing Auto-Tuning Errors 291
Er-14 Flashing Auto-Tuning Errors 291
Er-15 Flashing Auto-Tuning Errors 291
Er-16 Flashing Auto-Tuning Errors 291
Er-17 Flashing Auto-Tuning Errors 292
Er-18 Flashing Auto-Tuning Errors 292
Er-19 Flashing Auto-Tuning Errors 292
Er-20 Flashing Auto-Tuning Errors 292
Er-21 Flashing Auto-Tuning Errors 292
Er-25 Flashing Auto-Tuning Errors 292
Err (001F) Illuminated Fault 259
FAn (000F) Flashing Alarm 277
FAn (0017) Illuminated Fault 259
FAn1 (0413) Illuminated Fault 259
FbH (0028) Flashing Alarm 278
FbH (0041) Illuminated Fault 259
FbL (0027) Flashing Alarm 278
FbL (0028) Illuminated Fault 259
GF (0006) Illuminated Fault 260
HCA (0034) Flashing Alarm 278
iFEr -
Copy Function
Error
293
L24v (0021) Flashing Alarm 278
LF (001C) Illuminated Fault 260
LF2 (0036) Illuminated Fault 260
LoG Flashing Alarm 278
LSo (0051) Illuminated Fault 260
LT-1 (0035) Flashing Alarm 279
LT-2 (0036) Flashing Alarm 279
LT-3 (0043) Flashing Alarm 279
LT-4 (0044) Flashing Alarm 279
Display (Hex.) ALM LED Type Ref.
ndAT -
Copy Function
Error
293
nSE (0052) Illuminated Fault 261
oC (0007) Illuminated Fault 261
oFA00 (0101) Illuminated Fault 262
oFA01 (0102) Illuminated Fault 262
oFA02 (0103) Illuminated Fault 262
oFA03 to oFA06 (0104 to
0107)
Illuminated Fault 262
oFA10, oFA11 (0111,
0112)
Illuminated Fault 262
oFA12 to oFA17 (0113 to
0118)
Illuminated Fault 262
oFA30 to oFA43 (0131 to
013E)
Illuminated Fault 262
oFb00 (0201) Illuminated Fault 263
oFb01 (0202) Illuminated Fault 263
oFb02 (0203) Illuminated Fault 263
oFb03 to oFb11 (0204 to
0212)
Illuminated Fault 263
oFb12 to oFb17 (0213 to
0218)
Illuminated Fault 263
oFC00 (0301) Illuminated Fault 263
oFC01 (0302) Illuminated Fault 263
oFC02 (0303) Illuminated Fault 263
oFC03 to oFC11 (0304 to
0312)
Illuminated Fault 263
oFC12 to oFC17 (0313 to
0318)
Illuminated Fault 263
oFC50 to oFC55 (0351 to
0356)
Illuminated Fault 264
oH (0003) Flashing Alarm 279
oH (0009) Illuminated Fault 264
oH1 (000A) Illuminated Fault 264
oH2 (0004) Flashing Alarm 279
oH3 (001D) Illuminated Fault 264
oH3 (0022) Flashing Alarm 279
oH4 (0020) Illuminated Fault 265
oL1 (000B) Illuminated Fault 265
oL2 (000C) Illuminated Fault 266
oL3 (0005) Flashing Alarm 280
oL3 (000D) Illuminated Fault 266
oL4 (0006) Flashing Alarm 280
oL4 (000E) Illuminated Fault 266
oL5 (003D) Flashing Alarm 280
oL5 (0044) Illuminated Fault 266
oL7 (002B) Illuminated Fault 267
oPE01 Flashing
Parameter Setting
Errors
284
oPE02 Flashing
Parameter Setting
Errors
284
oPE03 Flashing
Parameter Setting
Errors
284
oPE05 Flashing
Parameter Setting
Errors
285
