11.8 H: TERMINALS
440 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
Setting Function Description Ref.
32 TrqDetect1NO
The terminal activates when the drive detects overtorque or undertorque.
ON : The output current/torque is more than the torque value set with L6-02 [Trq Det1 Level], or the level is less
than the torque value set with L6-02 for longer than the time set with L6-03 [Trq Det1 Time].
706
33 TrqDetect1NC
The terminal deactivates when the drive detects overtorque or undertorque.
OFF : The output current/torque is more than the torque value set with L6-02 [Trq Det1 Level], or the level is less
than the torque value set with L6-02 for longer than the time set with L6-03 [Trq Det1 Time].
707
37 TrqDetect2NO
The terminal activates when the drive detects overtorque or undertorque.
ON : The output current/torque is more than the torque value set with L6-05 [Trq Det2 Level], or the level is less
than the torque value set with L6-05 for longer than the time set with L6-06 [Trq Det2 Time].
707
38 TrqDetect2NC
The terminal deactivates when the drive detects overtorque or undertorque.
OFF : The output current/torque is more than the torque value set with L6-05 [Trq Det2 Level], or the level is less
than the torque value set with L6-05 for longer than the time set with L6-06 [Trq Det2 Time].
707
39 Timer Output
Use this setting when the drive uses the timer function as an output terminal.
707
3C Comparator 1
The monitor value set with H2-20 [Compare1 Mon.Selection] is on while in range of the time set with H2-24
[Compare1 On-Delay Time] and the values of H2-21 [Compare1 Low Limit] and H2-22 [Compare1 Up Limit] are
in range.
707
3D Comparator 2
The monitor value set with H2-26 [Compare2 Mon.Selection] is on while in range of the time set with H2-30
[Compare2 On-Delay Time] and the values of H2-27 [Compare2 Low Limit] and H2-28 [Compare2 Up Limit] are
in range.
708
3E PID Fbk Low
The activates when the drive detects FbL [PID Feedback Loss].
708
3F PID Fbk High
The terminal activates when the drive detects FbH [Excessive PID Feedback].
708
4A DC Bus Undervolt
The terminal activates when the DC bus voltage or control circuit power supply is less than the voltage set with
L2-05 [UV Detection Lvl (Uv1)]. The terminal also turns on when there is a fault with the DC bus voltage.
ON : The DC bus voltage is less than the setting value of L2-05.
OFF : The DC bus voltage is more than the setting value of L2-05.
709
4B FreqRef Loss
The terminal activates when the drive detects a loss of frequency reference.
709
4C BrkRes Fault
The terminal activates when the mounting-type braking resistor is overheating or when there is a braking transistor
fault.
709
4D Motor OL1
The terminal activates when the electronic thermal protection value of the motor overload protective function is a
minimum of 90% of the detection level.
709
4E Drive PreOH
The terminal activates when the drive heatsink temperature is at the level set with L8-02 [Overheat Alm Level].
709
4F PreOHTimeLim
The terminal activates when L8-03 = 4 [Overheat Pre-Alarm Selection = Run@L8-19 Rate] and oH [Heatsink
Overheat] does not clear after the drive decreases the frequency for 10 cycles.
709
60 BrkTransFault
The terminal activates when the internal braking transistor overheats and the drive detects an rr [Dynamic Braking
Transistor Fault] fault.
709
61 BrkTransOH
The terminal activates when the braking resistor overheats and the drive detects an rH [Braking Resistor Overheat]
fault.
710
62 Fan Alarm
The terminal activates when the drive detects a cooling fan failure in the drive.
710
63 Maintenance
The terminal activates when drive components are at their estimated maintenance period.
Tells the user about the maintenance period for these items:
• IGBT
• Cooling fan
• Capacitor
• Soft charge bypass relay
710
65 WattH Pulse
Outputs the pulse that shows the watt hours.
710
66 MechWeakDetect
The terminal activates when the drive detects mechanical weakening.
710
