12.5 E: MOTOR
618 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
Note:
• When A1-02 = 0, 1, 3 [Control Method = V/f Control, PG V/f Control, CLVector], the maximum value is 120.
• When A1-02 = 2, 4 [OLVector, Adv OLVector], the maximum value is 48.
Auto-Tuning automatically sets this parameter to the value of [Number of Motor Poles].
■ E2-05 Motor L-L Resistance
No.
(Hex.)
Name Description
Default
(Range)
E2-05
(0312)
Motor L-L Resistance
Sets the line-to-line resistance for the motor stator windings.
Determined by o2-04 and
C6-01
(0.000 - 65.000 Ω)
Note:
This value is the motor line-to-line resistance. Do not set this parameter with the single-phase resistance.
Auto-Tuning automatically sets this parameter. If you cannot do Auto-Tuning, use the test report from the motor
manufacturer. You can calculate the motor line-to-line resistance with one of these formulas:
• E-type insulation: [the resistance value (Ω) shown on the test report at 75 °C] × 0.92
• B-type insulation: [the resistance value (Ω) shown on the test report at 75 °C] × 0.92
• F-type insulation: [the resistance value (Ω) shown on the test report at 115 °C] × 0.87
■ E2-06 Motor Leak Inductance
No.
(Hex.)
Name Description
Default
(Range)
E2-06
(0313)
Motor Leak Inductance
Sets the voltage drop from motor leakage inductance when the motor is operating at the rated
frequency and rated current. This value is a percentage of Motor Rated Voltage.
Determined by o2-04 and
C6-01
(0.0 - 60.0%)
The drive automatically sets this parameter during Auto-Tuning.
Note:
The motor nameplate does not usually show the quantity of voltage drop. If you do not know the value of the motor leakage inductance,
contact the motor manufacturer to receive a copy of the motor test report.
■ E2-07 Mot Sat Coeff 1
No.
(Hex.)
Name Description
Default
(Range)
E2-07
(0314)
Mot Sat Coeff 1
Set the motor iron-core saturation coefficient when the magnetic flux is 50%.
0.50
(0.00 - 0.50)
Rotational Auto-Tuning automatically sets this parameter. The drive uses this coefficient when it operates with
constant output.
■ E2-08 Mot Sat Coeff 2
No.
(Hex.)
Name Description
Default
(Range)
E2-08
(0315)
Mot Sat Coeff 2
Sets the motor iron-core saturation coefficient at 75% of the magnetic flux.
0.75
(E2-07 - 0.75)
Rotational Auto-Tuning automatically sets this parameter. The drive uses this coefficient when it operates with
constant output.
■ E2-09 Motor Mech Loss
No.
(Hex.)
Name Description
Default
(Range)
E2-09
(0316)
Expert
Motor Mech Loss
Sets the mechanical loss of the motor. Motor rated power (kw) = 100.0%. Usually it is not
necessary to change this setting.
0.0%
(0.0 - 10.0%)
Adjust this parameter in these conditions. The drive adds the configured mechanical loss to the torque reference
value as a torque compensation value:
• There is a large quantity of torque loss from motor bearing friction.
• There is a large quantity of torque loss in fans and pumps.
