Guide to Components (mainly North America)
• Do not obstruct the ventilation holes by placing objects near them or leaning things against them. If
the machine overheats, a fault might occur.
Front and right view
1. ADF
Lower the ADF over originals placed on the exposure glass.
If you load a stack of originals in the ADF, the ADF will automatically feed the originals one by one.
2. Exposure glass
Place originals face down here.
3.
Control panel
See p.36 "Guide to the Names and Functions of the Machine's Control Panel".
4. Front cover
Open to access the inside of the machine.
5. Paper tray
Load paper here.
6. Paper tray unit (Tray 2 and Tray 3)
Load paper here.
7. Ventilation holes
Prevent overheating.
8. Main power switch
To operate the machine, the main power switch must be on. If it is off, turn the switch on.
