Entering the Subject
Allows you to enter a subject for the Internet Fax or e-mail document you want to send.
1.
Place the original, and then select the scan settings you require.
2.
Specify the sender.
For details, see “Sender Settings”.
3.
Press [TX Mode].
4.
Press [Subject].
5.
Enter the subject.
2. Other Transmission Features
174
