Sony XVS Series User Manual

280
DME 3D Trans Global menu
DME Effect menu
Skew Overall path settings for items
relating to skew are made
simultaneously.
Skew All
Skew X,
Skew Y
Paths for the X- and Y-axes
Aspect Path for aspect ratio
Pers Overall path settings for items
relating to perspective are made
simultaneously.
Pers All
Pers X, Pers
Y, Pers Z
Paths for the X-, Y-, and Z-axes
Axis Loc Overall path settings for items
relating to image rotation axis are
made simultaneously.
Axis All
Axis X, Axis
Y, Axis Z
Paths for the X-, Y-, and Z-axes
Item Paths that can be set
3D Trans Global All Overall path settings for three-
dimensional transform items in the
global channel are made
simultaneously.
Loc Size Overall path settings for items
relating to image size changes and
movement are made
simultaneously.
Loc Size All
Size Path for image size
Post Loc X,
Post Loc Y
Paths for the X- and Y-axes
Post Size Path for size
Loc XYZ Overall path settings for items
relating to image movement are
made simultaneously.
Loc XYZ All
Loc X, Loc Y,
Loc Z
Paths for the X-, Y- and Z-axes
Rot Overall path settings for items
relating to image rotation are made
simultaneously.
Rot All
Rot X, Rot Y,
Rot Z
Paths for the X-, Y-, and Z-axes
Spin Overall path settings for items
relating to spin are made
simultaneously.
Spin All
Spin Src X,
Spin Src Y,
Spin Src Z
Paths for the X-, Y- and Z-axes
Spin X, Spin
Y, Spin Z
Paths for the X-, Y- and Z-axes
Pers Overall path settings for items
relating to perspective are made
simultaneously.
Pers All
Pers X, Pers
Y, Pers Z
Paths for the X-, Y-, and Z-axes
Item Paths that can be set
Axis Loc Overall path settings for items
relating to image rotation axis are
made simultaneously.
Axis All
Axis X, Axis
Y, Axis Z
Paths for the X-, Y-, and Z-axes
Item Paths that can be set
Effect All Overall path settings for DME effect
items are made simultaneously.
Edge Overall path settings for edge items
are made simultaneously.
Edge All
Border Path for border
Crop/Edge
Soft
Path for crop/edge softness
Beveled
Edge
Path for beveled edge
Key Border Path for key border
Art Edge Path for art edge
Flex Shadow Path for flex shadow
Wipe Crop Path for wipe crop
Color Mix Path for color mix
Video Modify Overall path settings for video
modify items are made
simultaneously.
Video Modify
All
Defocus/Blur Path for defocus/blur
Multi Move Path for multi-move
Color Modify Path for color modify
Mosaic Path for mosaic
Mask Path for mask
Sketch Path for sketch
Metal Path for metal
Dim/Fade Path for dim/fade
Glow Path for glow
Freeze Path for freeze
Non-Linear Path for nonlinear effects
Corner Pin Path for corner pinning
Light Overall path settings for lighting
items are made simultaneously.
Light All
Lighting Path for lighting
Spot
Lighting
Path for spotlighting
Trail Path for trails
In/Out Overall path settings for items
relating to input/output are made
simultaneously.
In/Out All
Bkgd Path for background
Video/Key Path for video/key
Item Paths that can be set
