Sony XVS Series User Manual

387
Assigning a Function to a Memory
Recall Button in the Utility/Shotbox
Control Block
1 In the Engineering Setup >Panel >Prefs/Utility menu
(7324), press [Utility Module Assign].
The Utility Module Assign menu (7324.1) appears.
2 Select the target button to set.
3 In the <Action> group, select the function to assign.
Menu Shortcut: Assign a frequently used menu to be
recalled (menu shortcut).
Utility Command: Assign a function setting (utility
command).
Macro Recall: Assign a macro register recall.
Shotbox Recall: Assign a shotbox register recall.
4 Perform the following operations, according to the
selection in step 3.
When [Menu Shortcut] is selected: When the
memory recall button on the utility/shotbox
control block is blinking, display the shortcut
menu. Press the target memory recall button to set
to assign a shortcut. When finished, press [Menu
Shortcut] again.
When [Utility Command] is selected: Select a
command to assign in the list on the right side of
the status area.
a) DCU GPI Test Fire command only
When [Macro Recall] is selected: Select the macro
register to assign.
When [Shotbox Recall] is selected: Select the
shotbox register to assign.
5 Press [Action Set].
When [Menu Shortcut] is selected in step 3, it is not
necessary to press [Action Set].
To release the assignment
Select the target button to release, then press [Clear].
To display register names in the Utility Command
field
When [Macro Recall] or [Shotbox Recall] is selected in
step 3, you can select whether to display register names in
the Utility Command field.
To enable display, press [Reg Name Display], turning it
on.
List of utility commands and memory recall button states
The following table lists the utility commands that can be
assigned to memory recall buttons.
No. Parameter Adjustment
1 Bank Bank selection
2 Button No Memory recall button selection
No. Parameter Adjustment
3 Command Utility command selection
4
a)
GPI No GPI number
No. Parameter Adjustment
3 Macro Macro register selection
No. Parameter Adjustment
3 Shotbox Shotbox register selection
Command name Function Button state
Lit orange Lit dark blue
MEx PGM1 ST
a)
|
MEx PGM4 ST
a)
M/E-x PGM output safe title enable/
disable
x = 1 to 5
Enabled Disabled
MEx PVW ST
a)
M/E-x preview output safe title enable/
disable
x = 1 to 5
Enabled Disabled
MEx Clean ST
a)
M/E-x clean output safe title enable/
disable
x = 1 to 5
Enabled Disabled
MEx K-PVW ST
a)
M/E-x key preview output safe title
enable/disable
x = 1 to 5
Enabled Disabled
PP PGM1 ST
a)
|
PP PGM4 ST
a)
P/P PGM output safe title enable/
disable
Enabled Disabled
