322
To check the snapshot region: Press the
[SNAPSHOT] button, turning it on.
To check the effects region: Press the [EFF] button,
turning it on.
3
Press and hold the [STORE] button.
While the button is pressed, the button for the saved
region lights amber.
Shotbox Register Creation (Menu)
Creating a shotbox register
1
Open the Shotbox >Register >Store/Recall menu
(6411).
The status area shows the following settings for each
register.
Region settings: “Sxxx” is displayed if a snapshot is
assigned, and “Exxx” is displayed if an effect is
assigned (where xxx is the register number). The
register name is also displayed.
Lock status: When the register is locked (write-
protected), “L” is displayed.
Empty status: When the register is empty, “E” is
displayed.
Auto run enable/disable: When simultaneous effect
execution is enabled when they are recalled, “AR”
is displayed.
Shotbox register name: The shotbox register name is
displayed.
2
Switch the region display as required.
Press the button corresponding to the region you want
to display.
M/E: M/E-1 (“ME1”), M/E-2 (“ME2”), M/E-3
(“ME3”), M/E-4 (“ME4”), M/E-5 (“ME5”)
P/P: PGM/PST (“P/P”)
User: User1 (“USR1”), User2 (“USR2”), User3
(“USR3”), User4 (“USR4”), User5 (“USR5”),
User6 (“USR6”), User7 (“USR7”), User8
(“USR8”)
DME: DME ch1 (“DME1”), ch2 (“DME2”), ch3
(“DME3”), ch4 (“DME4”)
DEV1-8: Device1 (“DEV1”), Device2 (“DEV2”),
Device3 (“DEV3”), Device4 (“DEV4”), Device5
(“DEV5”), Device6 (“DEV6”), Device7
(“DEV7”), Device8 (“DEV8”)
DEV9-12: Device9 (“DEV9”), Device10 (“DEV10”),
Device11 (“DEV11”), Device12 (“DEV12”)
Misc: P-Bus (“PBUS”), GPI (“GPI”), Router
(“RTR”), Macro (“MCRO”)
3
Select a register.
4
Press [Edit].
The Edit menu (6411.1) appears.
You can also select the register in this menu using the
[Shotbox Reg] parameter.
In the status area, the shotbox register status for each
region appears.
5
Select a region.
You can select more than one region.
To select all regions, press [ALL]. To select all
switcher-related regions (M/E, P/P, User), press [SWR
ALL].
6
In the <Assign> group, select the snapshot or effect to
assign to the region.
Snapshot: Assign a snapshot.
Effect: Assign an effect.
If the selected register is locked, a confirmation
message appears asking whether or not to cancel the
operation. Press [OK] to return to the previous menu
display without carrying out the registration.
If the operation is carried out, the region selected in
step 5 is registered in the shotbox, and the parameters
become enabled.
7
Depending on the selection in step 6, set the following
parameter.
When [Snapshot] is selected
When [Effect] is selected
8
To execute the assigned effects at the same time as
they are recalled, press [Auto Run], turning it on.
9
Repeat steps 5 to 8 as required.
10
In the <Store> group, press [Store].
To return to the state before saving the setting
In the <Store> group, press [Undo].
To check settings by executing from the menu
Press [Recall] to execute the shotbox.
No. Parameter Adjustment
3 Snapshot Snapshot register number
No. Parameter Adjustment
3 Effect Effect register number
