TM9100 Service Manual Disassembly and Reassembly 123
© Tait Electronics Limited August 2005
5 Disassembly and Reassembly
This section describes how to:
■ remove and mount the control head
■ disassemble and reassemble the radio body
■ disassemble and reassemble the control head
General Important Before disassembling the radio, disconnect the radio from
any test equipment or power supply.
Disassemble only as much as necessary to replace the defective parts.
Inspect all disassembled parts for damage and replace them, if necessary.
Observe the torque settings indicated in the relevant figures.
For information on spare parts, refer to “Spare Parts” on page 421.
