Tait TM9100 Service Manual

TM9100 Service Manual Spare Parts 423
© Tait Electronics Limited August 2005
Table 15.1 Spare parts of the radio body
Pos. Description Qty. IPN Spares Kit
B
Cover 1 – TMAA22-02 mech. kit
C
Screw M4 x 16 6 349-02067-xx TMAA22-02 mech. kit
D
Lid 1 312-01091-xx –
E
Bung for aperture for external options connector 1 302-50000-xx TMAA22-02 mech. kit
F
Main seal 1 362-01109-xx TMAA22-02 mech. kit
G
Screw M3 x 10 8 349-02066-xx TMAA22-02 mech. kit
H
Main-board assembly (50W/40W radios)
Main-board assembly (25W radios)
1
1
XMAB34-yyzz
XMAB32-yyzz
TMAA22-34yyzz
TMAA22-32yyzz
I
Bung for auxiliary connector 1 302-50001-xx TMAA22-02 mech. kit
J
Seal for RF connector 1 362-01113-xx TMAA22-02 mech. kit
1)
Chassis (50W/40W radio)
Chassis (25W radio)
1
1
303-11301-xx
303-11225-xx
–
–
1!
Gap pad for chassis (50W/40W radio only) 1 369-01048-xx TMAA22-02 mech. kit
TMAA22-98 gap pad kit
1@
Control-head seal 1 362-01115-xx TMAA22-02 mech. kit
TMAA22-07 seals kit
1#
Screw for power connector (50W/40W radio)
Screw for power connector (25W radio)
2
2
346-10022-07
346-10030-08
–
1$
Auxiliary connector [SK101] 1 240-02022-xx –
1%
Inner foam seal for auxiliary connector 1 362-01110-xx TMAA22-02 mech. kit
1^
Outer foam seal for auxiliary connector 1 362-01112-xx TMAA22-02 mech. kit
1&
Lock-nut for auxiliary connector 1 354-01043-xx TMAA22-02 mech. kit
1*
Rubber seal for power connector (50W/40W radio)
Rubber seal for power connector (25W radio)
1
1
362-01127-xx
362-01114-xx
TMAA22-02 mech. kit
1(
Power connector [PL100] (50W/40W radio)
Power connector [
PL100] (25W radio)
1
1
240-00040-xx
240-00027-xx
–
2)
Gap pad for copper plate (50W/40W radio only) 1 369-01049-xx TMAA22-02 mech. kit
TMAA22-98 gap pad kit
2!
Heat-transfer block 1 308-13147-xx –
2@
Antenna connector [SK103] (mini-UHF), or
Antenna connector [
SK103] (BNC)
(both incl. lock washer and hexagonal nut)
1
1
240-00029-xx
240-00028-xx
–
The characters xx in an IPN stand for the issue number. Items will always be the latest issue at the time the
radio is manufactured.
The characters yy in an IPN or spares kit number stand for the abbreviated frequency band.
For more information, refer to “Frequency Bands” on page 14.
The characters zz in an IPN or spares kit number stand for the type of RF connector (00=BNC, 01=mini-UHF).
