276 Transmitter Fault Finding (50W/40W Radios) TM9100 Service Manual
© Tait Electronics Limited August 2005
Figure 11.14 PA circuitry under the
PAF TOP can (H5 and H7 bands)
H5, H7 BANDS
Q310
Q309
CIRCUITRY BETWEEN
IC301 AND PAs
VIA TO GATE OF Q310
VIA TO GATE OF Q309
VIA TO PIN 14 OF IC301
VIA TO PIN 8 OF IC301
