TM9100 Service Manual Fault Finding of Control Head 399
© Tait Electronics Limited August 2005
The following CCTM commands are used during the fault finding of the
remote control-head kit:
Table 14.2 CCTM commands for fault finding of the remote control-head kit
CCTM command Entry at keyboard Response on screen
1012 – Remote kit
turns the audio amplifier on and off
1012 0 = off
1012 1 = on
none
1013 – Mute audio amplifier
mutes and unmutes the audio amplifier
1012 0 = mute
1012 1 =unmute
none
1014 – Digital potentiometer
reads the digital potentiometer
1014 value between 0 and
255
1017 – Audio amplifier gain
sets the audio amplifier gain (4 levels)
1017 x
where x is the gain (0 to 3)
none
