Tait TM9100 Service Manual

Ref. IPN Description Ref. IPN Description
Ref. PCB Circuit Ref. PCB Circuit
Ref. PCB Circuit
474 Installing an Enhanced Remote Kit TM9100 Service Manual
© Tait Electronics Limited August 2005
C1 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C2 015-07470-10 Cap Cer 1206 4u7 X7r 16v
C3 015-06470-01 Cap Cer 1206 470n X7r 20% 50v
C4 018-13100-00 Cap 0603 100p 50v NPO ±5%
C7 015-27100-08 Cap Cer 0805 X7R 1uF 16V 10%
C9 018-13100-00 Cap 0603 100p 50v NPO ±5%
C10 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C13 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C101 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C102 015-07470-10 Cap Cer 1206 4u7 X7r 16v
C103 015-07470-10 Cap Cer 1206 4u7 X7r 16v
C203 018-13270-00 Cap 0603 270p 50v NPO±5%
C207 018-13270-00 Cap 0603 270p 50v NPO±5%
C209 018-13270-00 Cap 0603 270p 50v NPO±5%
C213 018-13270-00 Cap 0603 270p 50v NPO±5%
DS1 008-00014-73 LED Hp Grn Rang PCB Mtg
J1 240-10000-11 Conn SMD 18w Skt M/Match
J2 240-00016-00 Conn RJ45 Shld 8P8C LP RA TH
J3 240-00016-00 Conn RJ45 Shld 8P8C LP RA TH
R1 038-13120-00 Res 0603 120e 1/16w ± 5%
R2 038-10000-00 Res 0603 Zero 0hm 1/16w ± 5%
R3 038-14470-00 Res 0603 4k7 1/16w +-5%
R4 038-14470-00 Res 0603 4k7 1/16w +-5%
R6 038-15220-00 Res 0603 22k 1/16w +-5%
R7 038-15100-00 Res 0603 10k 1/16w +-5%
R8 038-15820-00 Res 0603 82k 1/16w +-5%
R9 038-13100-00 Res 0603 100e 1/16w ± 5%
R10 038-15100-00 Res 0603 10k 1/16w +-5%
R12 038-16100-00 Res 0603 100k 1/16w +-5%
R13 038-16100-00 Res 0603 100k 1/16w +-5%
R14 036-13560-00 Res M/F SMD 0805 560e 5%
R16 038-15100-00 Res 0603 10k 1/16w +-5%
R18 038-13220-00 Res 0603 220e 1/16w +-5%
R19 038-14120-00 Res 0603 1k2 1/16w +-5%
R30 038-13390-00 Res 0603 390e 1/16w +-5%
R31 038-13390-00 Res 0603 390e 1/16w +-5%
R103 038-12100-00 Res 0603 10e 1/16W ± 5%
R104 038-15100-00 Res 0603 10k 1/16w +-5%
R203 038-13100-00 Res 0603 100e 1/16w ± 5%
R207 038-13100-00 Res 0603 100e 1/16w ± 5%
R209 038-13100-00 Res 0603 100e 1/16w ± 5%
R213 038-13100-00 Res 0603 100e 1/16w ± 5%
R911 036-00000-00 Res 1206 0e 5% 0.125w
U1 002-19120-00 IC TS912ID Cmos R2R Opamp
U2 002-12523-17 IC LM317l Reg T0252 0.5a
U3 002-13483-00 IC XCVR RS485 LTD SLEW RATE 3V
220-01720-01 PCB MFX Radio Remote
219-02882-00 Loom Control Head TMA
302-10063-00 Brkt PCB Remote TM8200 Body
302-50002-00 Bung RJ45 MFO
316-06843-00 Pnl Frt Remote TM8200 MF0
346-10030-08 Scrw P/T Wn1412 Kc30x08 Zbc
349-02062-00 Scrw M3*8 T/T P/T ContiR
365-01762-00 Lbl TM8200 Branding Bullet
23.4.2 TMAC34-0T Torso Interface (PCB IPN 220-01720-01)
Parts List
Grid Reference List
C1 J2 1E2
C10 M2 1E6
C101 J1 1A4
C102 D1 1A3
C103 E2 1C4
C13 M2 1D6
C2 K1 1E1
C203 J2 1D4
C207 J2 1C5
C209 H2 1C3
C213 H2 1C3
C3 D2 1B2
C4 J1 1D3
C7 J2 1E4
C9 K2 1D5
DS1 F2 1A4
J1 H2 1C1
J2 L2 1D7
J3 N2 1C7
MT1 R2 1B5
R1 R1 1C5
R10 K2 1D5
R103 G2 1C4
R104 G2 1C3
R12 M2 1E6
R13 M2 1D6
R14 F2 1A4
R16 H2 1C3
R18 D2 1B3
R19 E2 1A3
R2 R1 1B5
R203 J2 1D3
R207 J2 1C5
R209 H2 1C3
R213 H2 1C3
R3 J1 1E2
R30 F2 1B6
R31 E2 1C6
R4 J1 1E2
R6 J1 1E2
R7 G2 1C3
R8 J1 1D3
R9 M2 1D4
R900 F2 1C5
R901 E2 1B5
R910 N2 1B7
R911 N2 1B7
R912 H2 1C2
R920 F2 1A1
R921 E2 1A1
R930 C2 1B1
R932 C2 1B1
TP2 N2 1A5
U1 K1 1E5 1E3 1A4
U2 D2 1B2
U3 F2 1B4
