TM9100 Service Manual Transmitter Fault Finding (50W/40W Radios) 251
© Tait Electronics Limited August 2005
Figure 11.3 Point for measuring the power supply to the PAs (H5 and H7 bands)
PAF TOP
H5, H7 BANDS
Q310
Q309
L310
MEASUREMENT POINT ON L310
