TM9100 Service Manual Transmitter Fault Finding (50W/40W Radios) 283
© Tait Electronics Limited August 2005
Figure 11.15 PA driver circuitry under the
PAD TOP can (B1 band)
PAD TOP
Q3504
B1 BAND
R327
C310
R324
Q306
COMPONENTS C310,
R324 AND R327
GATE OF Q306
