470 Installing an Enhanced Remote Kit TM9100 Service Manual
© Tait Electronics Limited August 2005
23.4 PCB Information
23.4.1 TMAA03-03 Control-Head Interface (PCB IPN 220-01721-02)
Parts List
C100 018-14101-00 Cap 0603 1n 50v NPO ±5%
C101 018-14101-00 Cap 0603 1n 50v NPO ±5%
C102 015-02470-06 Cap Cer 1210 47p NPO 500v
C103 015-02470-06 Cap Cer 1210 47p NPO 500v
C110 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C300 015-06470-01 Cap Cer 1206 470n X7r 20% 50v
C301 015-07220-08 Cap Cer 1206 2u2 16v X7r
C310 015-26100-08 Cap Cer 0805 100n 10% X7r 50v
C311 015-07220-08 Cap Cer 1206 2u2 16v X7r
C320 016-09100-07 Cap Elec SMD 100u 35v Loesr
C400 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C401 015-07220-08 Cap Cer 1206 2u2 16v X7r
C410 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C411 018-13100-00 Cap 0603 100p 50v NPO ±5%
C420 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C421 018-13100-00 Cap 0603 100p 50v NPO ±5%
C422 015-07220-08 Cap Cer 1206 2u2 16v X7r
C423 015-07220-08 Cap Cer 1206 2u2 16v X7r
C430 015-07220-08 Cap Cer 1206 2u2 16v X7r
C500 015-26100-08 Cap Cer 0805 100n 10% X7r 50v
C600 015-26100-08 Cap Cer 0805 100n 10% X7r 50v
C601 015-26100-08 Cap Cer 0805 100n 10% X7r 50v
C610 015-26100-08 Cap Cer 0805 100n 10% X7r 50v
C611 015-07220-08 Cap Cer 1206 2u2 16v X7r
C612 015-07220-08 Cap Cer 1206 2u2 16v X7r
C700 015-26100-08 Cap Cer 0805 100n 10% X7r 50v
C701 015-07220-08 Cap Cer 1206 2u2 16v X7r
C702 015-07220-08 Cap Cer 1206 2u2 16v X7r
C703 015-06470-01 Cap Cer 1206 470n X7r 20% 50v
C704 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C705 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C706 018-13220-00 Cap 0603 220p 50v NPO±5%
C707 015-06470-01 Cap Cer 1206 470n X7r 20% 50v
C708 015-07220-08 Cap Cer 1206 2u2 16v X7r
C710 015-07220-08 Cap Cer 1206 2u2 16v X7r
C711 015-07220-08 Cap Cer 1206 2u2 16v X7r
C712 015-07220-08 Cap Cer 1206 2u2 16v X7r
C730 015-26220-18 CAP CER 0805 220N 10% X7R 50V
C731 015-26220-18 CAP CER 0805 220N 10% X7R 50V
C732 018-14100-00 Cap 0603 1n 50v X7r ±10%
C733 018-14100-00 Cap 0603 1n 50v X7r ±10%
C734 015-07220-08 Cap Cer 1206 2u2 16v X7r
C735 015-07220-08 Cap Cer 1206 2u2 16v X7r
D100 001-10000-99 Diode SMD BAV99 D-Sw SOT23
D101 001-10000-99 Diode SMD BAV99 D-Sw SOT23
D102 001-10000-99 Diode SMD BAV99 D-Sw SOT23
D103 001-10000-99 Diode SMD BAV99 D-Sw SOT23
D104 001-10000-99 Diode SMD BAV99 D-Sw SOT23
D110 001-10084-91 Diode SMD BZX84C9V1 Zen SOT23
D201 001-10000-99 Diode SMD BAV99 D-Sw SOT23
D211 001-10000-99 Diode SMD BAV99 D-Sw SOT23
D300 001-10000-99 Diode SMD BAV99 D-Sw SOT23
D720 001-10841-10 Diode SMD BZX84C11v ZEN SOT23
D730 001-10014-03 Diode SMD MBRS140T3 Sch
D731 001-10014-03 Diode SMD MBRS140T3 Sch
E100 057-10081-06 Ind 1806 Blm41p750s Emi Supr
E101 057-10081-06 Ind 1806 Blm41p750s Emi Supr
E102 057-10600-05 Ind 0603 Blm11p600s .5a F/Bead
E103 057-10600-05 Ind 0603 Blm11p600s .5a F/Bead
E105 057-10081-06 Ind 1806 Blm41p750s Emi Supr
E710 057-10600-05 Ind 0603 Blm11p600s .5a F/Bead
E711 057-10081-06 Ind 1806 Blm41p750s Emi Supr
E730 057-10081-06 Ind 1806 Blm41p750s Emi Supr
E731 057-10081-06 Ind 1806 Blm41p750s Emi Supr
J100 240-00016-00 Conn RJ45 Shld 8P8C LP RA TH
J200 240-10000-11 Conn SMD 18w Skt M/Match
J201 240-10000-11 Conn SMD 18w Skt M/Match
L712 057-10100-65 Ind SMD Pwr Cdrh6D38 100UH .65
L730 057-10010-02 Ind SMD Pwr CDRH74 10UH 1.8A
L731 057-10010-02 Ind SMD Pwr CDRH74 10UH 1.8A
Q610 000-10084-71 Xstr BC847BW NPN SOT323
Q720 000-10084-71 Xstr BC847BW NPN SOT323
Q721 000-10442-70 Xstr SI4427DY PCH Pwr MFET SO8
R100 038-13100-00 Res 0603 100e 1/16w ± 5%
R110 038-15100-00 Res 0603 10k 1/16w +-5%
R200 038-13100-00 Res 0603 100e 1/16w ± 5%
R201 038-13100-00 Res 0603 100e 1/16w ± 5%
R202 038-13100-00 Res 0603 100e 1/16w ± 5%
R210 038-13100-00 Res 0603 100e 1/16w ± 5%
R211 038-13100-00 Res 0603 100e 1/16w ± 5%
R212 038-13100-00 Res 0603 100e 1/16w ± 5%
R300 038-14120-00 Res 0603 1k2 1/16w +-5%
R301 038-13220-00 Res 0603 220e 1/16w +-5%
R320 036-00000-00 Res 1206 0e 5% 0.125w
R401 038-14470-00 Res 0603 4k7 1/16w +-5%
R402 038-14470-00 Res 0603 4k7 1/16w +-5%
R410 038-15150-00 Res 0603 15k 1/16w +-5%
R411 038-16150-00 Res 0603 150k 1/16w +-5%
R412 038-13100-00 Res 0603 100e 1/16w ± 5%
R420 038-15330-00 Res 0603 33k 1/16w +-5%
R421 038-15220-00 Res 0603 22k 1/16w +-5%
R422 038-12470-00 Res 0603 47e 1/16w ± 5%
R430 038-14220-00 Res 0603 2k2 1/16w +-5%
R431 038-14220-00 Res 0603 2k2 1/16w +-5%
R441 038-14470-00 Res 0603 4k7 1/16w +-5%
R442 038-14470-00 Res 0603 4k7 1/16w +-5%
R501 038-15100-00 Res 0603 10k 1/16w +-5%
R510 038-13120-00 Res 0603 120e 1/16w ± 5%
R511 038-10000-00 Res 0603 Zero 0hm 1/16w ± 5%
R600 038-15100-00 Res 0603 10k 1/16w +-5%
R601 038-16470-00 Res 0603 470k 1/16w ± 5%
R602 038-10000-00 Res 0603 Zero 0hm 1/16w ± 5%
R603 038-10000-00 Res 0603 Zero 0hm 1/16w ± 5%
R604 038-10000-00 Res 0603 Zero 0hm 1/16w ± 5%
R605 038-10000-00 Res 0603 Zero 0hm 1/16w ± 5%
R606 038-15100-00 Res 0603 10k 1/16w +-5%
R607 038-15100-00 Res 0603 10k 1/16w +-5%
R608 038-15100-00 Res 0603 10k 1/16w +-5%
R609 038-15100-00 Res 0603 10k 1/16w +-5%
R611 038-15100-00 Res 0603 10k 1/16w +-5%
