TM9100 Service Manual Spare Parts 425
© Tait Electronics Limited August 2005
Table 15.2 Spare parts of the control head
Pos. Description Qty. IPN Spares Kit
a
B
M4 x 12 Taptite screw 2 349-02058-xx TMAA22-97
C
Adaptor flange 1 349-02067-xx
301-00020-xx
TMAA22-97
D
Control-head loom (with female-female adaptor)
– female-female adaptor
1 219-02882-xx
240-00021-41
TMAA22-97
E
3 x 10 PT screw 4 346-10030-xx TMAA22-97
F
Control-head board 1 – TMAA22-96 (x3)
G
Seal 2 362-01124-xx TMAA22-97
H
Short light pipe 1 262-00003-xx TMAA22-97
I
Long light pipe 1 262-00004-xx TMAA22-97
J
Space-frame 1 319-30077-xx TMAA22-97
1)
Speaker clamp 1 303-50111-xx TMAA22-97
1!
Speaker 1 252-00011-xx TMAA22-97
1@
LCD assembly 1 – TMAA22-94 (x3)
1#
Main keypad 1 311-03124-xx TMAA22-97
1$
Power keypad 1 311-03120-xx TMAA22-97
1%
Concealed microphone 1 – TMAA02-07
1^
Front panel assembly 1 – TMAA22-97
1&
Knob for volume-control potentiometer 1 311-01054-xx TMAA22-97
The characters xx in an IPN stand for the issue number. Items will always be the latest issue at the time the
radio is manufactured.
a. Spares kit TMAA22-97 contains an assembled control head without control-head board, concealed microphone
and LED assembly.
