16.6.2 TMAA02-08 Grid Reference List (PCB IPN 226-00145-04)
Top Side Components
Y1 H5 1G10
U2 G4 1K13
U1 H5 1G9
S9 D4 1F3
S8 C3 1E2
S7 C4 1F2
S6 C5 1F2
S5 C6 1G2
S4 A3 1E1
S3 A4 1F1
S2 A5 1F1
S18 F4 1J7
S16 C1 1E4
S15 C2 1F4
S14 D2 1F4
S13 A2 1G4
S12 D3 1E3
S11 D5 1F3
S10 D6 1G3
S1 A6 1G1
R9 G5 1G6
R8 G5 1G6
R7 J4 1H6
R6 G3 1K6
R5 G5 1H8
R45 H4 1J8
R44 H4 1G7
R43 H3 1J12
R42 H3 1J12
R4 G6 1D7
R37 H3 1J12
R36 G3 1J12
R35 G3 1K12
R34 G3 1H6
R33 H3 1K12
R32 H6 1B9
R31 H6 1B9
R30 H6 1B8
R3 G5 1D7
R25 H3 1K12
R22 J4 1F11
R21 H3 1H5
R20 J4 1B7
R2 J6 1D7
R19 H4 1G7
R18 H4 1F8
R17 J4 1B7
R15 G6 1G8
R14 J4 1B6
R12 G5 1G6
R11 G5 1G6
R10 G3 1K6
R1 J5 1D7
Q2 J6 1B8
Q1 J5 1B7
J9 K3 1F5 1E5 1G5
J7 K5 1D5 1B5
J5 J5 1F11
J4 J2 1E12
J3 J5 1F7
J2 G5 1G8
J12 J3 1E5
J11 D3 1E4
J1 G2 1J4
DS6 D2 1C3
DS5 B2 1C3
DS4 C4 1C3
DS3 B4 1C2
DS2 C5 1C2
DS1 B5 1C1
D4 H4 1F8
D3 F3 1K6 1K7
D2 G4 1J7 1H6
D1 J4 1H5
C8 G4 1H6
C7 J3 1H5
C6 F5 1J6
C5 J5 1F8
C4 H4 1J14
C3 H4 1J14
C2 H4 1J12
C1 H5 1H10
Bottom Side Components
TP9 J3 1F5
TP8 G5 1G5
TP7 H5 1G5
TP6 H3 1K5
TP5 G3 1K5
TP4 H3 1K5
TP3 D4 1E5
TP20 J5 1D6
TP2 E5 1B4
TP19 K5 1D6
TP18 J6 1D6
TP17 J6 1D5
TP16 G4 1J13
TP15 F3 1J6
TP14 G3 1J6
TP13 J5 1B5
TP12 K5 1B5
TP11 J3 1E5
TP10 J4 1E5
TP1 E5 1B4
R41 D5 1B4
R40 D5 1B3
R39 D5 1C3
R38 D5 1B3
R29 D5 1C3
R28 D6 1C2
R27 D6 1C2
R26 D6 1C1
R24 D5 1B2
R23 D4 1B1
R16 D5 1B3
R13 D4 1B2
J8 E5 1D5 1B5
J6 G6 1K8
J14 G4 1K8
J13 F5 1J6
J10 E3 1E5 1G5 1F5
R
e
f
.
PCB Ci
rcu
i
t
R
e
f
.
PCB Ci
rcu
i
t
