Xerox PrimeLink B9110 User Manual

LOADING ENVELOPES IN TRAY 5 (BYPASS)
Important: If you are using the XLS Bypass tray, before proceeding, loosen the four locking screws on the
paper guides. For details, refer to Loading Media in the Optional Extra Long Sheets (XLS) Bypass Tray.
Load envelopes in Tray 5 in the short-edge feed (SEF) or long-edge feed (LEF) direction.
LLooaaddiinngg EEnnvveellooppeess iinn TTrraayy 55 iinn tthhee SSEEFF DDiirreeccttiioonn
When loading envelopes in the SEF direction, ensure that the flaps are closed and face down. Position the envelope
flaps along the front of the tray.
LLooaaddiinngg EEnnvveellooppeess iinn TTrraayy 55 iinn tthhee LLEEFF DDiirreeccttiioonn
When loading envelopes in the LEF direction, ensure that the flaps are closed and face down. Position the envelope
flaps along the right side of the tray.
290
Xerox
®
PrimeLink
®
B9100/B9110/B9125/B9136 Copier/Printer User Guide
Tray 5 (Bypass)
