Clearing Paper Jams from Folder Area E10
1. Open the folder front cover.
2. To remove jammed paper, do the following:
a. Lift lever 22aa.
b. Rotate knob 22bb to the left.
c. Remove the jammed paper.
3. Return levers 22aa and 22bb to their original positions.
4. Close the folder front cover.
5. If the printer indicates that there are more paper jams, follow the instructions to clear the paper and to resume
printing.
408
Xerox
®
PrimeLink
®
B9100/B9110/B9125/B9136 Copier/Printer User Guide
C/Z Folder
