2000-OSM, F1 2-19
g. On the Manual Temperature Control Mode screen (see Figure 2-11), verify that the actual
temperature for the FPD is at least 120 degrees.
**** Manual Temperature Control Mode ****
Zone Config Actual SP Rate
ISO-OVEN ISO 79.9 80.0 0.0
PROG. OVEN PROG/C 220.1 220.0 0.0
FPD ISO 120.2 125.0 0.0
LSV ISO 199.9 200.0 0.0
Valve # : [0] Time : 0125
Zone # : 2 State : Pk Back
Set Point: 220.00
Ramp Rate: 30.0000 T-Rating Ver
VALVES : - - - - - - - - T2 290C
Accept Zero Span
Escape Control All All
Point Zones Zones
F1 F2 F3 F4
Figure 2-11. MANUAL TEMPERATURE CONTROL MODE SCREEN
h. When the temperature is at least 120 degrees, press the F1 (Escape) soft key two times to
return to the Manual Control Mode screen.
i. On the Manual Control Mode screen, press the F2 (Detector and Graphics) soft key.
j. On the Chroma Board screen, verify the flame is off and the Ignitor is Off.
k. Press the F4 (Manual Ignitor On) soft key to light the cell flame. The ignitor coil remains
powered for the specified Timeout period. Once the flame lights the Flame Out LED will go
off. The cell flame burns as long as there is sufficient burner air and hydrogen fuel in the cell.
14. With Dual Detectors, perform steps 12 and 13 for each detector, as appropriate.
15. Again verify settings with the Data Package and adjust as needed. Check oven temperature on
the Temperature Control screen (see "Temperature Control Table" in Section 4).
Verify GCC Operation
Restore all tables from E2PROM as follows:
