4-9 2000-OSM, F1
Parameters) soft key. On the Control Parameters screen (see Figure 4-9), cursor down the
selections until "Detector 1 Mode" and "Detector 2 Mode" appear. Select the desired mode for
Detector 2 and then press the F2 (Exit and Update) soft key to save this setting.
********** Control Parameters **********
Update Trends on Alarm: No
Yes
Auto Update of RF: No Yes
Max RF Variation: 0.000000
Unknown Peak RF: 0.000000
Unknown Peak Units: % ppm
Slope Detect Tics: Never Last First
Detector 1 Mode: Master
Detector 2 Mode: Master Slave
Analyzer Name:
More Below
Exit Alarm Common
Escape and Mask Digital
Update Out. Mask
F1 F2 F3 F4
Figure 4-9. CONTROL PARAMETERS SCREEN
The Stream Assignment screen adds two columns to its standard screen (see Figure 4-10), one to
identify the detector used for each stream and method (Det), the other to identify the link between
master and slave (Link).
****** Stream Assignment ******
Stream Status Method Basic Det Link
01 Active 01 00 01 02
02 Active 02 00 02 00
03 Active 01 00 01 04
04 Active 02 00 02 00
05 Inactive 01 00 01 00
06 Inactive 01 00 01 00
07 Inactive 01 00 01 00
08 Inactive 01 00 01 00
Exit
F1 F2 F3 F4
Figure 4-10. STREAM ASSIGNMENT SCREEN
