Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 199
Chapter 6
Configure Analog Outputs
Analog Expansion Module
The addition of a 1444-AOFX00-04RB Analog Output Expansion Module
enables analog outputs of 4…20 mA. The Dynamix™ 1444 series Analog
Output Expansion Module is a four-channel module that outputs 4…20 mA
signals. These signals are proportional to measured values of the host 1444-
DYN04-01RA dynamic measurement module.
The 1444-AOFX00-04RB module is designed for use with a dynamic
measurement module that acts as its host, serves its power, and manages the
analog configuration of the module.
The analog output expansion module is designed to act as an extension of its
host module. Therefore, the operation of the 1444-AOFX00-04RB module is
dependent on the availability of its host.
Topic Page
Analog Expansion Module 199
Output Configuration Page 200
