380 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
Configuration Group 23
Group 23 contains configuration attributes from the following objects:
• TSC Module Object (0x394)
• Measurement Alarm Object (0x396) Instances 1…5
Configuration Group 24
Group 24 contains configuration attributes from the Measurement Alarm
Object (0x396) Instances 6…12. Configuration Group 25
Table 104 - Configuration Group 23
Source Object Source Instance Source Attribute ID Name Data Type
0x394 1 17 Input Name 0 SINT[32]
217
Input Name 1 SINT[32]
0x396 1 18 Alarm Name SINT[32]
218Alarm Name SINT[32]
318Alarm Name
SINT[32]
418Alarm Name SINT[32]
518Alarm Name SINT[32]
Table 105 - Configuration Group 24
Source Object Source Instance Source Attribute ID Name Data Type
0x396 6 18 Alarm Name SINT[32]
7 18 Alarm Name SINT[32]
8 18 Alarm Name SINT[32]
9
18 Alarm Name SINT[32]
10
18 Alarm Name SINT[32]
11
18 Alarm Name SINT[32]
12
18 Alarm Name SINT[32]
