452 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
Attribute Semantics
Individual Alarm Status
Individual alarm status code can represent one or more of the following
conditions:
• Bit 0 - Alert usage enabled
• Bit 1 - Danger usage enabled
•Bit 2 - Adaptive mode
• Bit 3 - Profile mode
• Bit 4 - Multiplier configured
• Bit 5 - Multiplier active
•Bit 6 - Alert status
•Bit 7 - Danger status
Alarm Form
The following selection choices define the measurement alarm form.
Alarm Type
The following options define measurement alarm behavior that is related to
transducer status (TX OK).
Table 182 - Alarm Form
Value Description
0x00 (0) - Over Threshold
0x01 (1) - Outside Window
0x02 (2) - Under Threshold
0x03 (3) - Inside Window
Table 183 - Alarm Type
Value Description
0x00 TX OK Considered - requires TX OK status to report alarm condition
0x01 TX OK Monitored - forces an alarm when TX status is NOK
0x02 TX OK Not Considered - Don't care about TX OK state
