Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 439
CIP Objects Appendix A
Dynamix TSC Module Object
The TSC Module Object (class code 0x394) defines the setup for the Tacho
Signal Conditioning expansion module and interaction of this expansion
module with the main module.
Table 171 - Object Instances
Instance ID Description
0 TSC Module Class Instance
1 Instance 1 defines setup of TSC module input 0
2 Instance 2 defines setup of TSC module input 1
Table 172 - Class Attributes
Attribute ID Access Rule NV Name Data Type Description of Attribute Semantics of Values
1 Get NV Revision UINT Current object revision. Current revision.
8 Get NV Vendor ID UINT
9 Get NV Device Type UINT
10 Get NV Product Code UINT
11 Get NV Firmware Revision STRUCT Retrieves Firmware Revision of the TSC
expansion module.
Major Version USINT
Minor Version USINT
12 Get V Expansion Module Status WORD Coded information on TSC expansion
module operational status.
TSC status
13 Get NV Serial Number SHORT_STRING Warranty Serial Number 14 character max.
14 Get NV Product Name SHORT_STRING
15 Get V Transducer Status WORD Coded information on transducer (0/1)
operational status.
17 Get NV Auxiliary Link-Time Out UINT Link time out Fixed at 1000 ms (1 s)
18 Get V Mode Control BYTE Allows additional detection modes,
supports future capability such as
reverse rotation detection.
Fixed at zero.
