Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 367
CIP Objects Appendix A
Configuration Group 19
Group 19 contains configuration attributes from these objects:
• Current Output Module Object (0x39D)
• Normal CM Data Object (0x398)
• Advanced CM Data Object (0x39A)
• FFT Band Object (0x399) Instances 1…4
Table 101 - Configuration Group 19
Source Object Source Instance Source Attribute ID Name Data Type
0x39D 0 15 Current Module Control BYTE
- - - Pad SINT
- - - Pad INT
0x39D 0 16 Auxiliary Link time out UINT
0x39D 1 16 Current Output Enable SINT
- - - Pad SINT
0x39D 1 17 Current Output Measurement
Identifier
INT
0x39D 1 19 20 mA Output scaling REAL
0x39D 1 20 4 mA Output scaling REAL
0x39D 1 24 Current Output Not OK
Configuration
SINT
- - - Pad SINT
- - - Pad INT
0x39D 2 16 Current Output Enable SINT
- - - Pad SINT
0x39D 2 17 Current Output Measurement
Identifier
INT
0x39D 2 19 20 mA Output scaling REAL
0x39D 2 20 4 mA Output scaling REAL
0x39D 2 24 Current Output Not OK
Configuration
SINT
- - - Pad SINT
- - - Pad INT
0x39D 3 16 Current Output Enable SINT
- - - Pad SINT
0x39D 3 17 Current Output Measurement
Identifier
INT
0x39D 3 19 20 mA Output scaling REAL
0x39D 3 20 4 mA Output scaling REAL
0x39D 3 24 Current Output Not OK
Configuration
SINT
- - - Pad SINT
- - - Pad INT
0x39D 4 16 Current Output Enable SINT
