Install the Dynamix 1444 Series Monitoring System Chapter 2
Expansion Module Startup Behavior
During power-up, Expansion Module Status indicators provide the address
setting of the module. See Startup Behavior
on page 315 for more information.
Table 12 - Tacho Signal Conditioner Expansion Module
If the status indicators are not as shown in Tab le 12 , see Table 61 on page 276.
Table 13 - Relay Expansion Module
If the status indicators are not as shown in Tab le 13 , see Table 59 on page 276.
Table 14 - Analog Output Expansion Module
If the Status Indicators are not as shown in Ta b le 14 , see Table 71 on page 291.
Status Indicator Color Behavior Status Indicator Color Behavior
PWR Green Solid CH0 Green or
Blue
Solid
LNS Green Solid CH1 Green or
Blue
Solid
MS Green Flashing OP0 Green Solid
OP1 Green Solid
Status
Indicator
Color Behavior Status
Indicator
Color Behavior
PWR Green Solid R0 Green Solid
LNS Green Solid R1 Green Solid
MS Green Flashing R2 Green Solid
R3 Green Solid
Status
Indicator
Color Behavior Status
Indicator
Color Behavior
PWR Green Solid OP0 OFF
LNS Green Solid OP1 OFF
MS Green Flashing OP2 OFF
OP3 OFF
