492 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
Dynamix MUX Object
The Dynamix MUX Object (class 0x39B) defines and controls a multiplexing
capability of a main module. The appropriate choice of the Module Type
enables Multiplexing.
Multiplexing is not a means to connect different signals to the inputs. Rather it
is to provide a method to allow use of all four channels when the sample rate
requirement is greater than the module can perform continuously on four
channels.
9 Get V Time Slot 3
Settling Time
REAL Time Slot 3 Settling
Time
s
Time Slot Configuration Group of 4 configuration attributes.
16 Get V Time Slot 0 DAQ
Time Multiplier
INT Time Slot 0 DAQ Time
Multiplier
Range: 1…255
Default: 1
17 Get V Time Slot 1 DAQ
Time Multiplier
INT Time Slot 1 DAQ Time
Multiplier
Range: 1…255
Default: 1
18 Get V Time Slot 2 DAQ
Time Multiplier
INT Time Slot 2 DAQ Time
Multiplier
Range: 1…255
Default: 1
19 Get V Time Slot 3 DAQ
Time Multiplier
INT Time Slot 3 DAQ Time
Multiplier
Range: 1…255
Default: 1
Table 240 - Common Services
Service
Code
Implementation Service Name Description of Service
Class Instance
0x0E x x Get Attribute Single Returns the contents of the specified attribute
Table 241 - Object Instances
Instance ID Description
0 Class Instance for the MUX Object
1Instance 1
Table 242 - Object Attributes
Attribute
ID
Access Rule NV Name Data Type Description of
Attribute
Semantics
of Values
1 Get NV Revision UINT The MUX object
revision
-
8 Get NV MUX Configured BOOL Yes = this
configuration
uses MUX
1 = Yes
9 Get NV Number of
enabled
subchannels
USINT Not Used Fixed at 1
10 Get - Overall cycle time REAL Time to complete
to MUX cycle
s (actual
measured)
Table 239 - Instance Attributes (continued)
