Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 363
CIP Objects Appendix A
Configuration Group 18
Group 18 contains voted alarm object instances 8…13 and options to configure
the input and output assemblies.
See
Assembly Object on page 517, 0x04, for more on this configurability.
- - - Pad INT
0x397 7 33 Alarm Multiplier ON Time DINT
40 Speed Gating Control SINT
41 Speed Gating Detection SINT
- - - Pad INT
0x397 7 42 Lower Speed Threshold REAL
43 Higher Speed Threshold REAL
48 Logic gating source WORD
49 Logic gating sense USINT
56 Logic Control source WORD
Table 99 - Configuration Group 17 (continued)
Source Object Source Instance Source Attribute ID Name Data Type
Table 100 - Configuration Group 18
Source Object Source Instance Source Attribute ID Name Data Type
0x397 8 16 Alarm Usage BYTE
18 Alarm Behavior SINT
19 Alarm Type SINT
24 Alarm Logic Configuration SINT
25 Alarm Input 0 SINT
26 Alarm Input 1 SINT
27 Alarm Input 2 SINT
28 Alarm Input 3 SINT
32 Alarm Multiplier Control BYTE
- - - Pad SINT
- - - Pad INT
0x397 8 33 Alarm Multiplier ON Time DINT
40 Speed Gating Control SINT
41 Speed Gating Detection SINT
- - - Pad INT
0x397 8 42 Lower Speed Threshold REAL
43 Higher Speed Threshold REAL
48 Logic gating source WORD
49 Logic gating sense USINT
56 Logic Control source WORD
