Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 397
CIP Objects Appendix A
Dynamix Transient Data
Manager Object
The Transient Manager Object (class code 0x38C) defines the setup of
transient data acquisition mode and provides access to the associated transient
data buffers. Furthermore this object allows for transient type definition,
which can differentiate between normal and fast transients.
Object Instances
Instance ID Description
0 Transient Data Manager Class Instance
1 Transient Data Manager Setup Instance
Table 124 - Class Attributes
Attribute
ID
Access
Rule
NV Name Data Type Description of Attribute
1 Get NV Revision UINT Defines revision of Dynamix
Transient Data Manager Object
8 Get V Last Transient Event STRUCT Timestamp of the last transient
event.
8 bytes*
*The last transient event timestamp comprises two UDINT - sub-second resolution to one nanosecond followed by
seconds since 1970.
When transient capture is enabled it indicates the last detected transient event (since power-up) irrespective of
whether this is captured or stored by the module. For example the time stamp may be updated by a more recent
coast down where only run-ups are stored or by a transient event that occurs after all buffers have been used and
latched.
Table 125 - Instance Attributes
Attribute ID Access Rule NV Name Data Type Description of Attribute Semantics of Values
1 Get V Transient Static Records STRUCT The number of overall/static data records
currently stored in each of the four transient
buffers.
Four UINT Maximum: 640 per
2 Get V Transient Dynamic Records The number of dynamic data records
currently stored in each of the four transient
buffers.
Four UINT Maximum: 64 per
3 Get V Run-up Data-Set Usage BYTE Provide information as to which of the four
buffers are configured for Run-up data
storage
Bits 0…3 for the four normal
mode buffers.
4 Get V Coast-Down Data-Set Usage BYTE Provide information as to which of the four
buffers are configured for coast down data
storage
Bits 0…3 for the four normal
mode buffers.
5 Get V Transient Buffer Status DWORD Coded reference to the current status of each
of the four buffers such as: Free, Populating,
Data Ready, Processing, and Latched
conditions.
4 x4 bits for
the Normal
Transient
buffers.
High-level Transient Operation Group of 2 configuration attributes.
16 Get V Transient Data Mode Control WORD Configuration of transient data-collection
Mode (Normal or fast transient, buffer
allocations, and so on).
Range: 0…1825
18 Get V Transient - Dynamic Data
Source Selection
SINT Future functionality.
Default is whatever the Normal CM Data
defines.
Fixed value: 0
Transient Data Acquisition Group of 9 configuration attributes.
23 Get V Source of Speed Data SINT Source of speed data for transient data
acquisition.
Range: 1…4
